| Antwerpen 12 April 2011 |
|
Name |
HEINZ SCHEPERS |
|
Previous names |
Margret Margret |
|
Type |
Container ship |
|
IMO-number |
9061253 |
|
Call sign |
V2OM7 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. john's |
|
GT |
3.992 t |
|
DWT |
5.335 t |
|
NT |
2.233 t |
|
Number of 20ft containers |
509 |
|
Containers capacity 14t |
285 |
|
Reefer capacity |
52 |
|
Length |
101,11 m overall 96,13 m registered |
|
Breadth |
18,20 m registered |
|
Draught |
6,547 m |
|
Forecastle |
9,33 m |
|
Poop |
9,00 m |
|
Depth |
8,25 m moulded |
|
Speed |
Max.: 15,5 knots |
|
Built |
1993 |
|
Keel laid |
14.10.1992 |
|
Launch date |
10.08.1993 |
|
Date of completion |
10.1993 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. |
|
Yard number |
1083 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom |
|
Watertight bulkheads |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x Deutz MWM TBD645L9 - 4 stroke 9 cylinder 330 x 450 mm diesel engine - 3.825 kW at 600 rpm Reduced power: 2.175 kW Year of manufacture: 1993 Manufacturer: Deutz MWM Motoren-Werke Mannheim AG |
|
Propeller |
1x Controllable pitch propeller - aft at 162 rpm |
|
Electric installations |
1x Plant 380/220 V - 320 kVA 1x Plant 380/220 V - 320 kVA 1x Plant 380 V - 850 kVA 1x Plant 380 V - 40 kVA |
|
Shaft generator |
1x 850 kVA |
|
Generators |
2x Main diesel generatorsets each 320 kVA |
|
Emergency generator |
1x Diesel generatorset 40 kVA |
|
Compressed air receivers |
2x Receivers each 500 litres - 30,0 bar |
|
Bow thruster |
1x Fixed pitch propeller PLEUGER - 380 kW, forward |
|
Cargo capacity |
Grain: 7.275 m³ Bales: 7.015 m³ |
|
Tank capacities |
Fuel oil: 403 m³ Water ballast: 1.896 m³ |
|
Anchor equipment |
3x Anchors weight each 3.300 kg Chain length: 495,00 m |
|
Cargo gear |
None |
|
Crew size |
15 |
|
Manager |
HS Schiffahrts GmbH & Co. KG |
|
Owner |
HS Schiffahrts GmbH & Co. KG MS "Heinz Schepers" |
