Westerschelde 19 May 2014 |
Name |
CEMISLE |
Previous names |
2000 - 12.2005 Gdynia 2005 - 10.2007 Topaz 2007 - 02.2009 Grimsnis |
Type |
Cement carrier with pneumatical and mechanical self-discharging equipment |
IMO-number |
9213911 |
Call sign |
V2EE4 |
Flag |
Antigua & Barbuda |
Port of registry |
St. John's |
GT |
5.133 t |
DWT |
Summer: 6.885 t |
NT |
2.346 t |
Length |
119,95 m overall 113,33 m between perpendiculars |
Breadth |
16,60 m |
Draught |
6,67 m fully loaded |
Air draft |
Max.: 33,00 m from waterline basis |
Freeboard |
1.186 mm |
Speed |
13,0 knots |
Built |
2000 Transformation year: 02.2009 |
Date of completion |
07.2000 |
Builder |
Polnocna Shipyard Gdansk |
Yard number |
B196-III/1 |
Hull material |
Steel |
Continuous decks |
1 |
Main engine |
1x MAN B&W 8L32/40- 8 cylinder diesel engine - 3.840 kW / 5.217 hp at 750 rpm Built: 1999 Builder: H. Cegielski - Poznan S.A., Poznan - Poland |
Propellers |
1x Screw propeller controllable pitch |
Boilers |
1x CHR 110,00 m² - 10,0 bar 1x CHO 22,20 m² - 10,0 bar |
Shaft generator |
1x 650 kVA - 520 kW |
Generators |
2x Diesel generatorsets each 360 kVA - 288 kW - 432 hp 2x Diesel generatorsets 1.000 kVA each for discharging operation |
Emergency generator |
1x Diesel generatorset 125 kVA - 100 kW - 149 hp |
Number of holds |
4 |
Total capacity of holds |
Hold 1: 1.785 m³ Hold 2: 1.797 m³ Hold 3: 1.858 m³ Hold 4: 1.953 m³ Total: 7.393 m³ |
Loading equipment |
By gravity via one central loading point on portside (Diameter: 600 mm) or by pneumatic loading via eight (plus additional 4 points via central loading system (2 each hold)) ‘STORTZ’ couplings (100 mm / 4“) for loading from trucks/wagons at a rate up to 400 t/h. |
Discharging equipment |
By pneumatic discharge at an average of abt. 250-350 t/h to shore connections, via one 12“ outlet pipe, placed midships on portside and starboard side. Rate based on a distance of up to 100,00 m horizontal and up to 30,00 m elevation. A discharge into trucks / railwaggons (mechanical) is also possible at a rate of abt 150 t/h but from starboard side only. |
Tank capacities |
HFO: 268 t / 423,3 m³ Gas oil: 109 t Ballast water:2.569 m³ Fresh water: 82,0 m³ |
Fuel capacity |
423,3 m³ |
Manager |
Brise Bereederung Schaarsteinwegsbrücke 2 20459 Hamburg Germany |
Chartering |
Schifffahrtsgesellschaft mbH & Co. KG Schaarsteinwegsbrücke 2 20459 Hamburg Germany |
Registered owner |
MS 'CEM ISLE' Schifffahrtsgesellschaft mbH & Co. KG |
Latest data adjustment |
07 June 2014 |
