Name |
STEN IDUN |
|
Type |
Tank for chemicals and oil |
|
IMO-number |
9261102 |
|
Call sign |
ZDFM5 |
|
Flag |
Gibraltar |
|
Previous flags |
2002 - 2002 Norway |
|
Port of registry |
Gibraltar |
|
GT |
11.935 t |
|
DWT |
16.613 t |
|
NT |
5.137 t |
|
Length |
144,05 m overall 133,80 m between perpendiculars |
|
Breadth |
23,19 m extreme |
|
Draught |
8,90 m |
|
Keel to top mast |
44,50 m |
|
Freeboard |
3.511 mm |
|
Depth |
12,40 m |
|
Speed |
14,8 knots |
|
Built |
2002 |
|
Keel laid |
03/02/2002 |
|
Launch date |
26/05/2002 |
|
Date of completion |
20/12/2002 |
|
Builder |
Jiangnan Shipbuilding (Group) Co. Ltd. Feng Chan Village, Chang Xing Town Chongmin County Shanghai China |
|
Yard number |
H2285 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 8 Longitudinal: 1 |
|
Main engine |
1x Wärtsilä 6L46C - 4 stroke 6 cylinder 460 x 580 mm combustion engine 6.300 kW / 8.565 hp at 500 rpm Builder: Wärtsilä Finland Oy |
|
Propellers |
1x Fixed pitch propeller 4 blades Builder: Wärtsilä Propulsion Norway AS |
|
Boilers |
Auxiliary boiler, vertical shell type AQ-9 Auxiliary boiler, composite AQ-16 Builder: Aalborg Industries A/S |
|
Shaft generator |
1x AVK - 1.500 kW |
|
Generators |
1x Wärtsilä 6L20 2x Wärtsilä 4L20 Diesel generatorsets total 2.380 kW at 900 rpm Builder: Wärtsilä Finland Oy |
|
Emergency generator |
1x Sisue 634 diesel generatorset Builder: Sisue Diesel Inc. |
|
Bow thruster |
1x Brunvoll - 800 kW |
|
Number of cargo tanks |
12 |
|
Cargo capacity 98% |
18.491 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
681 m³ |
|
Total cargo capacity 98% |
19.172 m³ |
|
Number of segregations |
8 |
|
Cargo pumps |
12x Framo each 300 m³/h 2x Framo each 150 m³/h - portable pumps |
|
Pumping capacity |
2.100 m³/h |
|
Manifolds |
Bow to centre of manifold: 71,80 m |
|
Ballast capacity |
8.179,8 m³ |
|
Anchor equipment |
Length: 573,10 m Diameter: 58 mm |
|
Lifting equipment |
1x Hose crane - SWL 5,0 t |
|
Commerical manager |
Stenersen Chartering AS Vollsveien 2A 1366 Lysaker Norway |
|
ISM manager |
Rederiet Stenersen AS Solheimsgaten 13 N-5058 Bergen Norway |
|
Register owner |
Stenoil KS Care of Stenersen Chartering AS Vollsveien 2A 1366 Lysaker Norway |
|
Latest data adjustment |
11 August 2021 |
