Name |
SÜLLBERG |
|
Type |
Oil product tanker |
|
IMO-number |
9100114 |
|
Call sign |
CQIE2 |
|
Flag |
Portugal |
|
Port of registry |
Madiera |
|
Previous flags |
1994 - 2007 Germany 2007 - 2007 Antigua and Barbuda 2007 - 2017 Gibraltar - Call sign: ZDIC3 |
|
GT |
1.969 t |
|
DWT |
Summer: 3.459 t |
|
NT |
936 t |
|
Length |
89,99 m overall 84,99 m between perpendiculars |
|
Breadth |
12,50 m extreme |
|
Draught |
4,63 m |
|
Depth |
6,00 m |
|
Speed |
10,0 knots |
|
Built |
1994 Rebuild: 2007 |
|
Keel laid |
15/04/1994 |
|
Launch date |
29/07/1994 |
|
Date of completion |
30/09/1994 |
|
Builder |
Barkmeijer Stroobos B.V. Stroobos The Netherlands |
|
Yard number |
271 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Deutz MWM SBV6M628 - 6 cylinder combustion engine 1.235 kW Builder: MWM-Motores Diesels S.A. |
|
Propellers |
1x Solid propeller - 5 blades |
|
Boilers |
1x Thermal oil heater, oil fired type HE 10 H 40E |
|
Generators |
2x Valmet 620 DSG main diesel generatorset each 150 kVA 1x Cummins main diesel generatorset 500 kVA |
|
Emergency generator |
1x Valmet 320 DSG diesel generatorset |
|
Bow thruster |
1x Veth 275 hp / 200 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacities |
Tank 1 P&S: 327,20 m³ Tank 2 P&S: 285,77 m³ Tank 3 P&S: 288,36 m³ Tank 4 P&S: 143,40 m³ Tank 5 P&S: 319,80 m³ Tank 6 P&S: 364,92 m³ |
|
Pumps |
3x Vogelsang VX 100- 386 QD each 323 m³/h 1x Vogelsang V 100 - 90 Q HD - 10 m³/h |
|
Tank capacities |
Ballast: 1.481 m³ |
|
Anchor equipment |
Length: 412,50 m Diameter: 34 mm |
|
Lifting equipment |
1x Crane - SWL 0,9 t |
|
Crew size |
7 |
|
Manager |
Vega Reederei GmbH & Co. KG Große Elbstraße 145C 22767 Hamburg Germany |
|
Previous managers |
1994 - 2015 Vega-Reederei Friedrich Dauber GmbH & Co. KG |
|
Registered owner |
MT "SÜLLBERG" Bereederungs GmbH & Co. KG |
|
Previous owners |
1994 - 2007 Partenreederei MS "SÜLLBERG" |
|
Renamed |
12/2021 - 04/2022 JS Gratitude Republic of Panama, Panama City - Call sign: 3E2092 04/2022 JS Gratitude Nigeria - Call sign: 50YB Owner: JS Shipping & Trading Co Ltd., 101251 Apapa - Nigeria |
|
Latest data adjustment |
12 February 2022 |
