Name |
NORTHSEA BETA |
|
Previous names |
2010 Launch as: Pyxis Beta |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9547776 |
|
Call sign |
9HA2594 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flag |
2010 - 2010 Marshall Islands, Majuro - Call sign: V7SY5 |
|
GT |
5.256 t registered |
|
DWT |
Summer: 8.615 t Winter: 8.313,3 t |
|
NT |
2.847 t registered |
|
Displacement |
Summer: 11.751 t Winter: 11.449,7 t |
|
Length |
110,00 m overall |
|
Breadth |
18,60 m moulded |
|
Draught |
Summer: 7,80 m Winter: 7,72 m |
|
Moulded L x B x D |
104,74 x 18,60 x 10,00 m |
|
Registered L x B x D |
105,29 x 18,60 x 10,00 m |
|
Keel to mast end |
31,50 m |
|
Air draft |
Lightship: 27,00 m Normal ballast: 24,93 m At loaded summer .deadweight: 23,70 m |
|
Freeboard |
Summer: 2.211 mm Winter: 2.048 mm |
|
Depth |
10,00 m moulded |
|
Speed |
11,2 knots |
|
Built |
2010 |
|
Keel laid |
20/11/2008 |
|
Launch date |
29/06/2009 |
|
Date of completion |
25/05/2010 |
|
Builder |
Yangzhou Kejin Shipyard Co., Ltd. China |
|
Yard number |
KJ06045 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
11 |
|
Continuous decks |
1 |
|
Main engine |
1x ZJMD/MAN-B&W 8L27/38 - 4 stroke single acting 8 cylinder 270 x 380 mm combustion engine Mcr 2.720 kW / 3.696 hp at 800 rpm Built: 19/01/2009 Manufacturer: Zhenjiang Marine Diesel Works |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 320 mm |
|
Propellers |
1x Fixed pitch propeller - aft at 160 rpm |
|
Boilers |
1x CHR Jiangyin sanjie 80,0 m² - 7,0 bar 1x CHO Jiangyin sanjie 70,0 m² - 7,0 bar Manufacturer: JiangYin Sanjie Industry Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 450 kVA - 360 kW - 548 hp |
|
Bow thruster |
1x 385 kW |
|
Number of cargo tanks |
10 + 2 slop tanks |
|
Cargo tank capacity 98% |
Seg#1 (1P/S+2P/S): 3.677.,43 m³ (4.005,35 m³ with Slop Seg#2 (2P/S+3P/S): 3.653,343 m³ Seg#3 (5P/S): 1.897,095 m³ Total: 9.227;681 m³ excluding slop tanks |
|
Slop rank capacity 98% |
328,107 m³ |
|
Tank coating |
Phenolic epoxy |
|
Number of pumps |
3x Cargo pumps each 550 m³/h 2x Centrifugal ballast pumps each 150 m³/m³ |
|
Manifolds |
Bow to centre manifold: 53,50 m Stern to centre manifold: 56,50 m |
|
Tank capacities |
Fuel oil: 410,2 m³ Fresh water: 285 m³ Water ballast: 3.495 m³ |
|
Crew size |
16 |
|
Commercial manager |
Pyxis Maritime Corp 59, Konstantinou Karamanli Street Marousi, 151 25 Athens Greece |
|
ISM manager |
International Tanker Management Dubai Ltd. Office 809, Executive Heights, DAMAC Building Dubai United Arab Emirates. |
|
Registered owner |
Thirdone Corporation Ltd. - Marshall Island Care of Pyxis Maritime Corp. 59, Konstantinou Karamanli Street Marousi, 151 25 Athens Greece |
|
Renamed |
03/2022 Marine Moon Republic of Panama, Panama City - Call sign: 3E3431 Owner: Integrity Tankers Pte Ltd., 15-02, MTower, Singapore 119963 - Republic of Singapore Operator: ITM Holding Ltd. |
|
Latest data adjustment |
10 March 2024 |
