| Zeebrugge 17 November 2008 |
 |
|
|
| Zeebrugge 17/11/08 | Zeebrugge 17/11/08 |
|
Name |
CASSIOPEIA LEADER |
|
Type |
Vehicles carrier |
|
IMO-number |
9182277 |
|
Call sign |
3FND9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
57.455 t |
|
DWT |
21.547 t |
|
NT |
17.237 t |
|
Length |
199,94 m overall 199,00 m between perpendicular 194,27 m registered |
|
Breadth |
32,23 m overall |
|
Moulded L x B x D |
190,00 x 32,20 x 15,32 m |
|
Registered L x B x D |
194,27 x 32,20 x 23,53 m |
|
Draught |
Summer: 10,07 m |
|
Freeboard |
Summer: 5.295 mm |
|
Depth |
15,32 m |
|
Speed |
Service speed: 19,0 knots Trail speed: 21,0 knots |
|
Built |
1999 |
|
Keel laid |
30.06.1998 |
|
Launch date |
06.05.1999 |
|
First movement |
15.07.1999 |
|
Date of build |
14.07.1999 |
|
Builder |
Imabari Zosen |
|
Yard number |
1315 |
|
Hull type |
Single hull |
|
Main engine |
1x 2 stroke single acting 8 cylinder 600 x 2.200 mm engine - 14.121 kW at 100 rpm Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works |
|
Number of screws |
1 |
|
Boiler |
1x Auxiliary vertical boiler - 7,9 bar Evaporation: 4,99 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
4 x Main diesel generatorsets 4.275 kVA |
|
Lifting capacity |
3x Cranes SWL - 0,9 t 2x Cranes SWL - 4,0t |
|
Car capacity |
5.066 |
|
High car cap. 2,0 m |
4.345 |
|
Ramp loadable |
150 t |
|
Tank capacities |
Fuel oil: 3.288 m³ Fresh water: 419 m³ Water ballast: 9.293 m³ |
|
Crew |
21 |
|
Manager |
Wilhelmsen Lines |
|
Operator |
NYK - Nippon Yusen Kaisha Line |
|
Owner |
Alberni Shipholding S.A. Panama Republic of Panama |
