| Zeebrugge 13 June 201 |
 |
 |
|
| Zeebrugge 13/06/12 | Zeebrugge 13/06/12 |
|
Name |
CITY OF OSLO |
|
Type |
Vehicle carrier |
|
IMO-number |
9407677 |
|
Call sign |
9VGR2 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
20.209 t Suez: 21.918 t Panama: 68.116 t |
|
DWT |
Summer: 4.693 t |
|
NT |
6.062 t Suez: 19.873 t Panama: 19.601 t |
|
Light weight |
6.866 t |
|
Length |
139,99 m overall 131,00 m between perpendiculars |
|
Breadth |
22,43 m moulded |
|
Draught |
Summer: 6,10 m |
|
Depth |
17,30 m moulded |
|
Speed |
Service: 18,0 knots |
|
Built |
2010 |
|
Keel laid |
16.12.2008 |
|
Launch date |
18.12.2009 |
|
Date of completion |
31.03.2010 |
|
Builder |
Kyokuyo Shipyard Corporation |
|
Yard number |
487 |
|
Hull material |
Steel |
|
Main engine |
2x Mak 6M43C - output 10.800 kW Builder: Caterpillar Motoren GmbH & Co. KG |
|
Propeller |
1x 4 blades controllable pitch |
|
Boilers |
1x Auxiliary boiler, horizontal shell type - BH-1500 2x Auxiliary boiler, exhaust gas smoke tube - Mission XW Builder: Aalborg Industries |
|
Generators |
2x Daihatsu 6DC-17 diesel generatorsets each 2.400 kW Builder: Daihatsu Diesel Mfg. Co. Ltd Moriyama Factory |
|
Emergency generator |
1x Cummins 6CT-8.3-D(M) diesel generatorset |
|
Bow thruster |
1.300 kW |
|
Number of cars |
2.000 |
|
Stern ramp |
Size: 15,90 x 7,00 m Load Base: 75 t |
|
Stern quarter ramp |
Position: Starboard Size: 16,30 x 5,00 m Load base: 30 t |
|
Deck area |
16.125 m² |
|
Tank capacities |
Water ballast: 3.251,50 m³ Fresh water: 134,7 m³ Fuel oil: 1.147,2 m³ Diesel oil: 100,3 m³ |
|
Anchor |
Length: 577,5 m Diameter: 58 mm |
|
Crew |
14 |
|
Manager |
OSM Ship Management Pte. Ltd. |
|
Owner |
Gram Car Carriers |
|
Registered owner |
Gram Car Carriers Pte. Ltd. |
