Name
|
GLOVIS STELLA
|
|
Korean name
|
글로비스 스텔라
|
|
Type
|
Roll-On/Roll-Off carrier
PCC - Pure Car Carrier
|
|
IMO-number
|
9749570
|
|
Call sign
|
D7HA
|
|
Flag
|
South Korea
|
|
Port of registry
|
Jeju
|
|
Previous flags
|
2016 - 2023 Marshall Islands, Majuro - Call sign: V7NN9
|
|
GT
|
65.748 t
|
|
DWT
|
19.638 t
|
|
NT
|
22.928 t
|
|
Length
|
199,97 m overall
|
|
Breadth
|
35,40 m
|
|
Draught
|
Summer: 10,02 m
|
|
Reg. dimensions L x B x D
|
194,32 x 35,40 x 20,52 m
|
|
Rule dimensions L x B x D
|
188,80 x 35,40 x 35,60 m
|
|
Freeboard
|
Summer: 3.140 mm
|
|
Depth
|
20,52 m
|
|
Speed
|
Max: 20,0 knots
|
|
Built
|
2016
|
|
Keel laid
|
24/08/2015
|
|
Launch date
|
25/10/2015
|
|
Date of completion
|
08/01/2016
|
|
Builder
|
Hyundai Samho Heavy Industries Co., Ltd.
Yeongam
South Korea
|
|
Yard number
|
S806
|
|
Hull material
|
Steel
|
|
Main engine
|
1x 2 stroke single acting 7 cylinder 600 x 2.400 mm combustion engine 13.070 kW at 102,0 rpm
Build: 16/04/2015
Builder: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea
|
|
Propellers
|
1
|
|
Boilers
|
1x Auxiliary Boiler WTB - 8,8 kg/cm²
Heating Surface: 30,20 m³
1x Economizer EGE - 11,8 kg/cm²
Heating Surface: 393,00 m³
Build: 26/06/2015
Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea
|
|
Generators
|
1x Generatorset 1.250 kVA - 450 Volt
2x Generatorsets 1.875 kVA - 450 Volt
|
|
Number of cars
|
7.400
|
|
Tank capacities
|
Fuel oil: 3.410,9 m³
Fresh water: 313,5 m³
Water ballast: 9.203,0 m³
|
|
Commercial manager
|
Hyundai Glovis Co., Ltd.
|
|
ISM manager
|
G-Marine Service Co., Ltd.
|
|
Registered owner
|
Hyundai Glovis Co., Ltd.
|
|
Latest data adjustment
|
23 May 2023
|
