Westerschelde 24 June 2014 |
 |
| Zeebrugge 31/10/11 |
|
Name |
DELPHINUS LEADER |
|
Type |
Vehicles carrier |
|
IMO-number |
9174282 |
|
Call sign |
3FTD8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
57.391 t |
|
DWT |
21.514 t |
|
NT |
17.218 t |
|
Length |
199,94 m |
|
Breadth |
32,20 m |
|
Draught |
Summer: 10,066 m |
|
Moulded L x B x D |
190,00 x 32,20 x 15,32 m |
|
Registered L x B x D |
194,27 x 32,20 x 23,53 m |
|
Freeboard |
Summer: 5.295 mm |
|
Depth |
15,32 m moulded |
|
Speed |
Service: 19,5 knots Trial: 21,0 knots |
|
Built |
1998 |
|
Keel laid |
22.10.1997 |
|
Launch date |
09.07.1998 |
|
Date of completion |
31.08.1998 |
|
Builder |
Imabari Shipbuilding Co., Ltd. Marugame Headquarters |
|
Yard number |
1295 |
|
Main engine |
1x 2 Stroke single acting 8 cylinder 600 x 2.200 engine - 14.121 kW at 100,0 rpm Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works |
|
Number of screws |
1 |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device |
|
Boilers |
1x Auxiliary vertical boiler - 7,9 bar Evaporation: 4,99 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
4x Main diesel generatorsets - 4.275 kVA |
|
Car capacity |
5.066 |
|
High car cap. 2,00 m |
4.345 |
|
Ramp loadable |
150,0 t |
|
Tank capacities |
Fuel oil: 3.288 m³ Fresh water: 420 m³ Water ballast : 9.293 m³ |
|
Lifting equipment |
3x Cranes - SWL 0,9 t 2x Cranes - SWL 4,0 t |
|
Crew |
23 |
|
Manager |
Hachiuma Steamship Co., Ltd. |
|
Operator |
NYK-Line - Nippon Yusen Kaisha Line |
|
Registered owners |
Milford Shipholding S.A. Milford Shipholding II S.A. |
