Jinsei Maru - IMO 8913514

Name

JINSEI MARU

Type

Roll-On/Roll-Off vehicles carrier
PCC - Pure Car Carrier

IMO-number

8913514

Call sign

D5QC3

Flag

Liberia

Port of registry

Monrovia

Previous flag

1990 - 2018 Japan, Tokyo - Call sign: JNNB

GT

58.117 t

DWT

17.032 t

NT

17.435 t

Length

198,60 m overall
188,00 m between perpendiculars
192,79 m registered

Breadth

32,20 m over all

Moulded L x B x D

188,00 x 32,20 x 14,30 m

Registered L x B x D

192,79 x 32,20 x 22,18 m

Draught

9,673 m

Freeboard

Summer: 4.665 mm

Depth

14,30 m moulded

Speed

Max: 21,6 knots

Built

1990

Keel laid

20/10/1989

Launch date

10/01/1990

Date of completion

23/03/1990

Builder

Oshima Shipbuilding Co. Ltd.
Oshima
Japan

Yard number

10122

Hull material

Steel

Hull type

Single hull

Main engine

1x Mitsubishi - 2 stroke single acting 7 cylinder 600 x 2.200 mm combustion engine 12.356 kW at 100 rpm
Manufacturer: Mitsubishi Heavy Industries, Ltd.

Propeller shaft

1x Oil lubtiction shaft with monitoring device
Diameter: 560 mm

Number of screws

1

Boiler

1x Auxiliary vertical boiler - 6,9 bar
Evaporation: 2,97 t/h
Manufacturer: Gadelius K.K. (Kajiwara Tekkosho)

Generators

4x Generatorsets total 3.989 kVA

Cargo capacity

TEU: 255
Cars: 4.985
Cars / trucks: 4.050 / 245

High car cap. height 2,0 m

2.651

Ramp loadable

200 t

Lifting equipment

1x Crane SWL - 0,5 t
2x Cranes SWL - 0,9 t each
3x Cranes SWL - 4,0 t each

Tank capacities

Fuel oil: 2.869 m³
Fresh water: 352 m³
Water ballast: 7.361 m³

Crew

22

Manager

Hachiuma Steamship co. Ltd.
Tokyo
Japan

Operator

NYK - Nippon Yusen Kaisha Line

Owner

NYK Line - Nippon Yusen Kaisha Line
Tokyo
Japan

Registered owner

Nippon Yusen Kabushiki Kaisha

Scrapped

12/01/2020 Beached at Alang - India

Latest data adjustment

09 March 2020
