Kaijin - IMO 9053505

Name

KAIJIN

Type

Vehicles Carrier
PCC - Pure Car Carrier

IMO-number

9053505

Call sign

3FWI3

Flag

Republic of Panama

Port of registry

Panama

GT

41.931 t

DWT

17.183 t

NT

12.580 t

Length

195,54 m overall
185,00 m between perpendiculars
188,14 m registered

Breadth

28,80 m overall

Moulded L x B x D

185,00 x 28,80 x 12,04 m

Registered L x B x D

188,14 x 28,80 x 20,51 m

Draught

Summer: 9,02 m

Freeboard

Summer: 3.049 mm

Depth

12,04 m

Speed

18,8 knots

Built

1994

Keel laid

24.01.1992

Date of launch

28.09.1993

Date of Build

27.01.1994

Builder

K.K. Kanasashi Heavy Industries Co. Ltd. Toyohashi Works
Shimizu
Japan

Yard number

3310

Hull type

Single hull

Main engine

1x Mitsubishi - 2 stroke single acting 7 cylinder 600 x 1.900 mm diesel engine - 14.698 hp / 10.810 kW at 110,0 rpm
Manufacturer: Kobe Diesel Co., Ltd. Kobe Works

Number of screws

1

Boiler

1x Auxiliary vertical boiler - 6,9 bar
Evaporation: 3,23 t/h
Manufacturer: Tortoise Engineering Co., Ltd.

Generators

4x Main diesel generatorsets each 3.135 kVA

Cargo capacity

Cars: 4.413

High car cap. height 2,0 m

2.618

Ramp loadable

50 t

Cranes

2x Cranes - SWL 4,0 t each

Tank capacities

Fuel oil: 2.626 m³
Fresh water: 262 m³
Water ballast: 6.143 m³

Manager

NYK Shipmanagement Pte. Ltd.
Tokyo
Japan

Shipping company

NYK - Nippon Yusen Kaisha

Owner

Swift Shipholding SA
Panama
Republic of Panama

Registered owner

Swift Shipholding S.A.
