| Westerschelde 30 August 2018 |
 |
 |
 |
 |
 |
||||
| Westerschelde 28/01/12 | Westerschelde28/01/12 | Westerschelde11/02/12 | Westerschelde 02/12/11 | Westerschelde 13/05/15 | ||||
|
Name |
MAGNOLIA SEAWAYS |
|
Previous names |
15/10/2003 - 05/07/2011 Tor Magnolia |
|
Type |
Roll-On/Roll-Off carrier |
|
IMO-number |
9259496 |
|
Call sign |
OWKY2 |
|
Flag |
Denmark |
|
Port of registered |
Copenhagen |
|
Previous flag |
10/2003 - 07/2006 Denmark, Copenhagen - Call sign: OXFO2 07/2009 - 2013 Sweden, Gothenburg- Call sign: SKZN |
|
GT |
32.523 t |
|
DWT |
10.407 t |
|
NT |
9.757 t |
|
Container capacity 20 ft |
90 |
|
Length |
199,80 m overall 195,27 m between perpendiculars |
|
Breadth |
26,95 m extreme 26,50 m moulded |
|
Draught |
Summer: 7,35 m |
|
Lane metres |
3.831 m |
|
Lane width |
3,00 m |
|
Depth |
16,95 m |
|
Speed |
Service: 22,5 knots Max.: 25,0 knots |
|
Routes |
20/10/2003 - 18/07/2006 Gothenburg - Immingham |
|
Built |
2003 |
|
Keel laid |
17/02/2003 |
|
Launch date |
23/05/2003 |
|
Date of completion |
17/10/2003 |
|
Builder |
Flensburger Schiffsbau KG Flensburg Germany |
|
Yard number |
721 |
|
Hull material |
Higher tensile steel |
|
Main engine |
1x Hyundai/MAN-B&W 9L60MC-C - 2 stroke single acting 9 cylinder 600 x 2.022 mm combustion engine Mcr 20.070 kW / 27.287 hp at 123,0 rpm Builder: Hyundai Heavy Industries Co., Ltd. - South Korea |
|
Propeller |
1x Controllable pitch propeller at at 123,0 rpm |
|
Generators |
1x MAN D2840LE - 4 stroke 10 cylinder 128 x 142 mm diesel engine Mcr 495 kW 4x MAN-B&W 8L21/31 - 4 stroke 9 cylinder 210 x 310 mm diesel engine engines each Mcr 1.720 kW connected with generators each 1.630 kW / 400 Volt 50 Hz |
|
Bow thruster |
2x Controllable pitch thrusters each 1.100 kW / 1.496 bhp, forward 2x Controllable pitch thrusters each 880 kW / 1.196 bhp, aft |
|
Number of decks |
3 |
|
Passengers |
12 |
|
Number of berths |
12 |
|
Crew size |
14 |
|
Manager |
DFDS A/S Marmorvej 18 Copenhagen Denmark |
|
Operator |
18/07/2006 Tor Line AB, Gothenburg - Sweden |
|
Previous operator |
15/10/2003 - 18/07/2006 DFDS Tor Line - Denmark |
|
Registered owner |
DFDS Seaways AB Sydatlanten 6 SE-418 34 Göteborg Sweden |
|
Latest data adjustment |
04 June 2022 |
