| Ciutadella, Menorca 10 June 2013 |
 |
| Ciutadella 10/06/13 |
|
Name |
NURA NOVA |
|
Previous names |
1977-14.02.1986 Emsland 1986-11.04.1989 Bohus 1989-20.11.1989 St. Julien 1989-02.1992 Ostersjoen 02.1992-04.1992 Jon 1992-128.03.2001 Elba Nova |
|
Type |
Roll-On/Roll-Off vessel - Ferry |
|
IMO-number |
7701914 |
|
Call sign |
EATE |
|
Flag |
Spain |
|
Port of registry |
Santa Cruz De Tenerife |
|
Previous flags |
1977 - 1983 Republic of Singapore, Singapore City 1983 - 1986 Germany, Emden 1986 - 1989 Norway, Sandefjord 1989 - 1992 Sweden, Dalarö 1992 - 1998 Republic of Panama, Panama City |
|
GT |
3.134 t |
|
DWT |
Summer: 633 t |
|
NT |
940 t |
|
Lane metres |
190 |
|
Number of 20ft containers |
24 |
|
Length |
78,52 m overall 71,20 m registered |
|
Breadth |
13,62 m registered |
|
Draught |
3,74 m |
|
Depth |
9,35 m moulded |
|
Speed |
Service: 14,0 knots Max.: 15,0 knots |
|
Routes |
08.1977 - 1978 Eemshaven - Esbjerg 1978 Neustadt - Rønne 08.1978 - 12.1978 Emden - Eemshaven 06.1979 11.1979 Algeciras - Ceuta 04.1984 Saint Malo - Jersey - Guernsey 04.1984 - 1985 Emden - Borkum 06.1985 - 08.1985 Borgholm - Rønne - Travemünde 03.1986 - 04.1989 Sandefjord - Strömstad 05.1889 - 10.1989 Weymouth - Alderney - Jersey - Guernsey 05.1990 - 1992 Ystad - Rønne 04.1992 - 1994 Piombino - Portoferraio 10.1994 - 03.1995 Saint Malo - Jersey - Guernsey 1998 Alcudia - Ciutadella de Menorca |
|
Built |
1977 |
|
Keel laid |
07.02.1977 |
|
Launch date |
03.04.1977 |
|
Date of completion |
01.08.1977 |
|
Builder |
Usuki Iron Works Ltd. Usuki Shipyard |
|
Yard number |
975 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
12 |
|
Continuous decks |
2 |
|
Main engine |
2x Niigata 6MG31FZE - 4 stroke 6 cylinder 310 x 380 mm diesel engines - each 1.471 kW at 600 rpm Year of manufacture: 1977 Manufacturer: Niigata Engineering Co., Ltd. |
|
Propellers |
2x Solid propeller (keyless) - aft at 271 rpm |
|
Boilers |
1x Water heater, oil fired - 1,0 bar Heating surface: 11,0 m² Year of manufacture: 1977 |
|
Electric installations |
2x Plants each 380/220 V - 625 kVA 1x Plant 380 V - 75 kVA |
|
Generators |
2x Main diesel generatorsets each 625 kVA |
|
Emergency generator |
1x Diesel generatorset 75 kVA |
|
Compressed air receivers |
2x Receivers each 500 litres - 30,0 bar 2x Receivers each 100 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster Nakashima - 230 kW, forward |
|
Tank capacities |
Fuel oil: 184 m³ Ballast water: 182 m³ |
|
Number of cars |
86 |
|
Number of passengers |
377 |
|
Anchor equipment |
3x Anchors weight each 1.740 kg Chain length: 440,00 m |
|
Crew size |
33 |
|
Manager |
Formentera Cargo SL Spain |
|
Previous managers |
Iscomar |
|
Registered owner |
Formentera Cargo SL Spain |
|
Previous owners |
Nascentia Internacional, S.L. |
|
Last update |
23 February 2017 |
