| Oostende 27 March 2010 |
 |
 |
 |
||
| Oostende 27/03/10 | Oostende 25/03/10 | Oostende 25/03/10 |
|
Name |
OSTEND SPIRIT |
|
Previous name |
1990-1998 Prins Filip - R.M.T. 1998-1999 Stena Royal - P&O Stena Line 1999-2002 P&OSL Aquitaine - P&O Stena Line 2002-2003 PO Aquitaine - P&O Ferries 2003-2005 Pride of Aquitaine - P&O Ferries 2005-2010 Norman Spirit - LD Lines |
|
Type |
Roll-On/Roll-Off carrier - Ferry |
|
IMO-number |
8908466 |
|
Call sign |
MMUC3 |
|
Flag |
United Kingdom |
|
Port of registry |
Ramsgate |
|
GT |
28.833 t |
|
DWT |
4.286 t |
|
NT |
11.596 t |
|
Length |
163,61 m overall 150,00 m between perpendiculars |
|
Breadth |
27,70 m over all |
|
Draught |
6,35 m |
|
Lane metres |
1.745 |
|
Freeboard |
2.877 mm |
|
Depth |
9,20 m |
|
Speed |
21,0 knots |
|
Line |
Oostende - Ramsgate |
|
Built |
1991 Rebuild: 1999 |
|
Keel laid |
02.05.1990 |
|
Date of completion |
22.10.1991 |
|
Builder |
Boelwerf Vlaanderen Shipbuilding |
|
Yard number |
1534 |
|
Hull type |
Single hull |
|
Watertight compartments |
15 |
|
Continuous decks |
11 |
|
Main engine |
4x Sulzer Bros 8ZAL40S - 4 stroke 8 cylinder 400 x 560 mm diesel engines - 21.120 kW / 28.696 hp at 510 rpm Built: 1990 Builder: Jugoturbina, Karlovac - Croatia |
|
Propelling system |
2x Screw propeller controllable pitch - at 141 rpm |
|
Boilers |
2x CHM 75,00 m² - 21,0 bar |
|
Electrical installation |
Power voltage: 660 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Generators |
4x Main diesel generatorsets each 1.719 kVA - 1.375 kW - 2.238 hp |
|
Fuel capacity |
1.035 m³ |
|
Passengers |
1.850 |
|
Number of cars |
250 |
|
Number of trucks |
75 |
|
Manager |
Transeuropa Shipping Lines Ltd., |
|
Operator |
TransEuropa Ferries - LD Lines |
|
Owner |
Louis Dreyfus Armateurs S.A.S. |
|
Previous owners |
1991-1998 R.M.T 1998-2005 Stena Ferries |
|
Renamed |
2011 Norman Spirit |
