Antwerpen 26 May 2016 |
 |
 |
 |
||
| Antwerpen 26/05/16 | Antwerpen 03/05/16 | Antwerpen 24/07/14 |
|
Name |
CITY OF ANTWERP |
|
Previous names |
1988 - 07.1990 Hyundai No.203 1990 - 11.1992 Atlantic Beauty 1992 - 01.2012 Hyundai No.203 |
|
Type |
Roll-On/Roll-Off vessel - Car carrier PCC - Pure car carrier |
|
IMO-number |
8709133 |
|
Call sign |
3FRY8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
41.353 t |
|
DWT |
Summer: 12.761 t |
|
NT |
12.405 t |
|
Length |
183,70 m overall |
|
Breadth |
30,60 m |
|
Draught |
8,16 m |
|
Reg. Dimensions L x Bx D |
176,75 x 30,60 x 19,32 m |
|
Rule Dimensions L x B x D |
174,00 x 30,60 x 14,21 m |
|
Depth |
19,32 m registered |
|
Speed |
18,8 knots |
|
Built |
1988 |
|
Keel laid |
28.07.1987 |
|
Launch date |
25.11.1987 |
|
Date of completion |
25.01.1988 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. |
|
Yard number |
H-602 |
|
Hull material |
Steel |
|
Watertight bulkheads |
Transverse: 4 |
|
Main engine |
1x 2 stroke single acting 6 cylinder 600 x 1.944 mm diesel engine - 10.591 kW at 111,0 rpm Built: 08.1987 Builder: Hyundai Engine & Machinery Co., Ltd., Ulsan - South Korea |
|
Propellers |
1 |
|
Boilers |
Built: 08.1987 Builder: Hyundai Heavy Industries Co., Ltd., Ulsan - South Korea |
|
Generators |
3x Main diesel generatorsets each 812 kVA - 450 Volt |
|
Number of decks |
11 |
|
Number of cars |
4.583 |
|
Tank capacities |
Fuel oil: 2.921,7 m³ Fresh water: 430,6 m³ Water ballast: 8.805,6 m³ |
|
Manager |
AML Ship Management GMBH |
|
Technical manager |
AML Ship Management GMBH |
|
Operator |
Abou Merhi Lines |
|
Owner |
Berytus Maritime Ltd. |
|
Latest data adjustment |
03 October 2014 |
