Zeebrugge 13 April 2014 |
 |
 |
 |
 |
|||
| Zeebrugge 13/04/15 | Zeebrugge 13/04/15 | Zeebrugge 13/04/15 | Zeebrugge 13/04/15 |
|
Name |
IVORY ARROW |
|
Type |
Roll-On/Roll-Off vehicle carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9277838 |
|
Call sign |
C6TM4 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
57.718 t |
|
DWT |
Summer: 21.300 t |
|
NT |
21.037 t |
|
Length |
199,98 m overall 187,90 m between perpendiculars |
|
Breadth |
32,25 m 32,40 m extreme |
|
Draught |
Summer: 10,00 m |
|
Air draft |
45,64 m |
|
Freeboard |
3.646 mm |
|
Depth |
19,98 m |
|
Speed |
Max.: 20,5 knots |
|
Built |
2004 |
|
Keel laid |
26.09.2003 |
|
Launch date |
15.05.2004 |
|
Date of completion |
29.06.2004 |
|
Builder |
Gdynia Shipyard (Stocznia Gdynia S.A.) |
|
Yard number |
8168/7 |
|
Hull material |
Steel |
|
Watertight bulkheads |
Transverse: 3 |
|
Main engine |
1x Sulzer/Cegielski 7RTA62U - 7 cylinder diesel engine 15.519 kW / 21.130 hp Builder: Wärtsilä NSD Switzerland Ltd. |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated AV-7 1x Auxiliary boiler, oil/gas fired Mission OS Builder: Aalborg Industries A/S |
|
Generators |
3x MAN B&W 7L28/32H diesel generatorsets |
|
Emergency generator |
1x MAN D2866LXE30 diesel generatorset Builder: MAN Nutzfahrzeuge AG |
|
Number of cars |
6.260 |
|
Number of decks |
14 |
|
Ballast capacity |
7.910 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Crew |
29 |
|
Technical manager |
Stamco Shipmanagement Co., Ltd. |
|
Owner |
Ray Car Carriers |
|
Registered owner |
Ivory Maritime Limited |
|
Latest data adjustment |
29 April 2015 |
