Westerschelde 29 June 2015 |
 |
 |
 |
 |
|||
| Westerschelde 29/06/15 | Westerschelde 30/10/15 | Westerschelde 12/08/19 | Westerschelde 12/08/19 |
|
Name |
GRANDE ATLANTICO |
|
Type |
RoCon - Roll-On/Roll-Off vehicle and container carrier |
|
IMO-number |
9130951 |
|
Call sign |
9HA5235 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flag |
1999 - 2009 Italy 2009 - 2009 Sweden 2009 - 2020 Gibraltar, Gibraltar - Call sign: ZDJO5 |
|
GT |
56.642 t registered |
|
DWT |
Summer: 26.195 t |
|
NT |
16.992 t |
|
Number of 20ft containers |
1.321 |
|
Length |
213,90 m overall 195,00 m between perpendiculars |
|
Breadth |
32,25 m moulded |
|
Draught |
9,20 m |
|
Freeboard |
2.314 mm |
|
Depth |
12,86 m moulded |
|
Speed |
Max.: 20,0 knots Service: 18,5 knots |
|
Built |
1999 |
|
Keel laid |
25/07/1996 |
|
Launch date |
17/04/1999 |
|
Delivery date |
21/07/1999 |
|
Builder |
Fincantieri-Cantieri Navali Italiani S.p.A - Palermo Shipyard Palermo Italy |
|
Yard number |
5986 |
|
Hull material |
High strength steel |
|
Hull type |
Single hull |
|
Watertight bulkheads |
13 |
|
Main engine |
1x Wärtsilä 7RTA62U - 2 stroke 7 cylinder combustion engine 15.540 kW / 21.127 bhp at 113,0 rpm Builder: Fincantieri-Cantieri Navale S.p.A.(Sulzer), Trieste - Italy |
|
Propellers |
1x Controllable pitch propeller |
|
Shaft generator |
1x 1.450 kW |
|
Generators |
3x Main diesel generatorsets each 960 kW |
|
Bow thruster |
1x 1.600 kW, forward 1x 1.600 kW, aft |
|
Number of decks |
11 |
|
Number of cars |
3.515 |
|
Number of trucks |
194 |
|
Number of tanks |
Ballast: 36 Fuel oil: 15 Lubricating oil: 6 Diesel oil: 4 Waste Water: 3 Fresh Water: 3 Chain: 2 Sludge: 1 |
|
Tank capacities |
Diesel Oil: 415,0 m³ Freshwater: 593 m³ Fuel Oil: 3.439,5 m³ Lube Oil: 209,1 m³ Tank Ballast: 17.540,2 m³ |
|
Cargo gear |
2x Deck cranes - SWL 40,0 t each |
|
Crew size |
19 |
|
Manager |
Atlantic Container Line AB Maskingatan 5 Gothenburg 417 64 Sweden |
|
Operator |
Grimaldi Compagnia di Navigazione S.p.A. Naples Italy |
|
Owner |
Atlantic Container Line Westfield NJ U.S.A. |
|
Registered owner |
ACL Invest AB |
|
Latest data adjustment |
17 August 2020 |
