Zeebrugge 10 May 2017 |
 |
 |
 |
||
| Zeebrugge 10/05/17 | Zeebrugge 10/05/17 | Zeebrugge 10/05/17 |
|
Name |
SILVER SOUL |
|
Previous names |
1988 - 02.2011 Cypress Pass 02.2011 - 11.2012 NOCC Caribbean |
|
Type |
Roll-On/Roll-Off carrier - PCTC - Vehicle carrier |
|
IMO-number |
8718706 |
|
Call sign |
HP3446 |
|
Flag |
Republic of panama |
|
Port of registry |
Panama City |
|
GT |
42.447 t registered |
|
DWT |
12.763 t |
|
NT |
12.734 t registered |
|
Length |
183,90 m overall 174,00 m between perpendiculars |
|
Breadth |
30,64 m |
|
Draught |
Summer: 8,21 m |
|
Freeboard |
6.021 mm |
|
Depth |
30,23 m |
|
Speed |
Service: 15,0 knots Max.: 17,0 knots |
|
Built |
1988 |
|
Date of completion |
05.03.1988 |
|
Builder |
Hyundai Heavy Industries |
|
Hull material |
Steel |
|
Main engine |
1x MAN B&W/HYUNDAI 8L60MCE - 2 stroke 8 cylinder 600 x 1.400 mm diesel engine 10.742 kW / 14.595 hp at 111,0 rpm Builder: Hyundai Heavy Industries Co. Ltd., Ulsan - South Korea |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHM 20,00 m² - 7,5 bar |
|
Generators |
3x MAN B&W 6L23/30 main diesel generatorsets each 813 kVA - 650 kW - 883 hp 440-220 VAC / 60Hz |
|
Emergency generator |
1x MAN diesel generatorset 100 kW |
|
Bow thruster |
1x 930 kW |
|
Car capacity |
4.247 |
|
Car deck area |
42.920 m² |
|
Liftable decks |
7 |
|
Ramps |
Stern ramp: Width: 7,25 m Door height: 10,00 m Deck height: 4,30 m SWL 25,0 t Side ramp: Width: 5,00 m Deck height: 2,20 m SWL 10,0 t |
|
Ventilators |
38x Han Bo Marine Machinery HAD-1200 ventilators each 1.200 m³ / h capacity |
|
Pumps |
2x Shin Shin SG 250D ballast pumps each 900 m³/h |
|
Tank capacities |
Fuel oil: 3.057,56 m³ |
|
Crew |
23 |
|
Manager |
Sallaum Lines DMCC (Head office) Swiss Tower |
|
Operator |
Sallaum Lines |
|
Registered owner |
Sallaum Lines S.A. |
|
Latest data adjustment |
16 May 2017 |
