Name |
GLOVIS CONDOR |
|
Korean name |
글로비스 콘도르 |
|
Previous names |
01/2011 - 08/2013 STX Dove |
|
Type |
Roll-On/Roll-Off vehicles carrier |
|
IMO-number |
9414876 |
|
Call sign |
D7GI |
|
Flag |
South Korea |
|
Port of registry |
Jeju |
|
Previous flag |
01/2011 - 09/2019 Marshall islands, Majuro - Call sign: V7VI4 |
|
GT |
60.552 |
|
DWT |
22.351 t |
|
NT |
27.052 |
|
Length |
199,10 m overall |
|
Breadth |
32,36 m |
|
Draught |
Summer: 11,22 m |
|
Reg. Dimensions L x B x D |
192,89 x 32,26 x 19,65 m |
|
Rule Dimensions L x B x D |
190,50 x 32,26 x 14,30 m |
|
Freeboard |
3.115 mm |
|
Depth |
14,30 m |
|
Speed |
20,4 knots |
|
Built |
2011 |
|
Keel laid |
22/12/2008 |
|
Launch date |
05/07/2010 |
|
Date of completion |
20/01/2011 |
|
Builder |
STX Dalian Shipbuilding Co., Ltd. Dalian China |
|
Yard number |
D-1002 |
|
Hull material |
Steel |
|
Watertight bulkheads |
Transverse: 4 |
|
Number of decks |
7 |
|
Main engine |
1x MAN-B&W 6S60MC-C - 2 stroke single acting 6 cylinder 600 x 2.400 mm combustion engine 14.280 kW at 105,0 rpm Builder: STX Heavy Industries Co., Ltd., Changwon - South Korea |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary water tube boiler Pressure: 8,8 kg/cm² Heating surface: 76,2 m² 1x Economizer exhaust gas boiler Pressure: 11,8 kg/cm² Heating surface: 394 m² Built: 08/2009 Kangrim Heavy Industrial Co., Ltd.,Changwon - South Korea |
|
Generators |
3x Generatorsets each 1.625 kVA / 450 Volt |
|
Number of cars |
6.700 |
|
Tank capacities |
Fuel oil: 3.842,5 m³ Fresh water: 256,7 m³ Water ballast: 9.126,6 m³ |
|
Crew |
24 |
|
Commercial manager |
Hyundai Glovis Co., Ltd. 83-21, Wangsimni-ro, Seongdong-gu Seoul South Korea |
|
Technical manager |
G-Marine Service Co., Ltd. 331, Jungang-daero, Dong-gu Busan, 48792 South Korea |
|
Registered owner |
Hyundai Glovis Co., Ltd. 83-21, Wangsimni-ro, Seongdong-gu Seoul South Korea |
|
Previous owner |
GL Condor Shipping, Inc. Marshall islands |
|
Latest data adjustment |
26 April 2025 |
