Name
|
KASSIE
|
|
Previous names
|
1988 - 07.1990 Hyundai No.203
1990 - 11.1992 Atlantic Beauty
1992 - 01.2012 Hyundai No.203
01.2012 - 09.2017 City of Antwerp
|
|
Type
|
Roll-On/Roll-Off carrier - Vehicle carrier
PCC - Pure car carrier
|
|
IMO-number
|
8709133
|
|
Call sign
|
V4RE3
|
|
Flag
|
Saint Kitts and Nevis
|
|
Previous flags
|
Republic of Panama
|
|
GT
|
41.353 t
|
|
DWT
|
Summer: 12.761 t
|
|
NT
|
12.405 t
|
|
Length
|
183,70 m overall
|
|
Breadth
|
30,60 m
|
|
Draught
|
8,16 m
|
|
Reg. Dimensions L x Bx D
|
176,75 x 30,60 x 19,32 m
|
|
Rule Dimensions L x B x D
|
174,00 x 30,60 x 14,21 m
|
|
Depth
|
19,32 m registered
|
|
Speed
|
18,8 knots
|
|
Built
|
1988
|
|
Keel laid
|
28.07.1987
|
|
Launch date
|
25.11.1987
|
|
Date of completion
|
25.01.1988
|
|
Builder
|
Hyundai Heavy Industries Co., Ltd.
Ulsan
South Korea
|
|
Yard number
|
H-602
|
|
Hull material
|
Steel
|
|
Watertight bulkheads
|
Transverse: 4
|
|
Main engine
|
1x 2 stroke single acting 6 cylinder 600 x 1.944 mm diesel engine - 10.591 kW at 111,0 rpm
Built: 08.1987
Builder: Hyundai Engine & Machinery Co., Ltd., Ulsan - South Korea
|
|
Propellers
|
1
|
|
Boilers
|
Built: 08.1987
Builder: Hyundai Heavy Industries Co., Ltd., Ulsan - South Korea
|
|
Generators
|
3x Main diesel generatorsets each 812 kVA - 450 Volt
|
|
Number of decks
|
11
|
|
Number of cars
|
4.583
|
|
Tank capacities
|
Fuel oil: 2.921,7 m³
Fresh water: 430,6 m³
Water ballast: 8.805,6 m³
|
|
Owner
|
Abou Merhi Lines
Beirut
Lebanon
|
|
Scrapped as
|
23/12/2017
Yong Chang
Saint Kitts and Nevis - Call sign: V4RE3
|
|
Latest data adjustment
|
16 March 2018
|
