Name |
GRANDE BRASILE |
|
Type |
Roll-On/Roll-Off carrier - RoCon |
|
IMO-number |
9198123 |
|
Call sign |
9HA5236 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2000 - 2003 Italy 2003 - 2009 Sweden - Call sign: SDCK 2009 - 2020 Gibraltar - Call sign: ZDJO4 |
|
GT |
56.660 t |
|
DWT |
Summer: 26.195 t |
|
NT |
18.251 t |
|
Number of 20ft containers |
1.321 |
|
Length |
213,88 m overall 195,00 m between perpendiculars |
|
Breadth |
32,28 m |
|
Draught |
Max: 9,41 m |
|
Keel to mast end |
55,00 m |
|
Depth |
12,00 m |
|
Speed |
Max: 19,9 knots |
|
Built |
2000 |
|
Keel laid |
01/10/1999 |
|
Launch date |
19/02/2000 |
|
Delivery date |
31/05/2000 |
|
Builder |
Fincantieri Cantieri Navali Italiani S.P.A. Palermo Italy |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
7 |
|
Number of decks decks |
11 |
|
Main engine |
1x Wärtsilä 7RTA62U - 2 stroke 7 cylinder 620 x 2.150 mm combustion engine 15.540 kW / 21.128 hp |
|
Propellers |
1x Controllable pitch propeller |
|
Generators |
4x Diesel generatorsets each 1.080 kW 1x Diesel generatorset 1.440 kW |
|
Bow thruster |
1.600 kW, forward 1.600 kW aft |
|
Number of cars |
3.515 |
|
Number of trucks |
194 |
|
Ramps |
1x Starboard aft: 34,50 x 8,50 m 150 t |
|
Number of tanks |
Ballast: 36 Fuel Oil: 15 Lubricating Oil: 6 Diesel Oil: 4 Waste Water: 3 Fresh Water: 3 Chain: 2 Sludge: 1 |
|
Tank capacities |
Diesel oil: 373;5 t Freshwater: 593 t Fuel oil: 3.370,71 t Lube oil: 188,19 t Tank ballast: 17.978,70 t |
|
Cargo gear |
2x Cranes - SWL 40 t each |
|
Crew size |
19 |
|
Number of passengers |
12 |
|
Commercial manager |
Grimaldi Group Spa Via Marchese Campodisola 13 80133 Naples NA Italy |
|
ISM manager |
Grimaldi Deep Sea Spa Via Marchese Campodisola 13 80133 Naples NA Italy |
|
Registered owner |
ACL - Atlantic Container Line invest 2003 AB Westfield NJ USA |
|
Group |
Grimaldi Group Spa |
|
Latest data adjustment |
01 March 2023 |
