Westerschelde 23 July 2019 |
 |
 |
|
| Westerschelde 23/07/16 | Westerschelde 20/05/17 | |
|
Name |
MORNING LISA |
|
Type |
Roll-On/Roll-Off carrier - Vehicle carrier PCC - Pure Car Carrier |
|
IMO-number |
9383417 |
|
Call sign |
3FRO6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
68.701 t |
|
DWT |
Summer: 28.084 t |
|
NT |
24.507 t |
|
Length |
232,37 m overall 222,40 m between perpendiculars |
|
Breadth |
32,30 m extreme 32,26 m moulded |
|
Draught |
Max: 10,02 m |
|
Reg. dimensions L x B x D |
225,52 x 32,26 x 20,11 m |
|
Rule dimensions L x B x D |
222,40 x 32,26 x 14,30 m |
|
Freeboard |
3.020 mm |
|
Depth |
20,11 m |
|
Speed |
Max: 19,6 knots |
|
Built |
2008 |
|
Keel laid |
13/05/2008 |
|
Launch date |
02/08/2008 |
|
Date of completion |
05/11/2008 |
|
Builder |
Hyundai Samho Heavy Industries Co. Ltd. Incheon South Korea |
|
Yard number |
S330 |
|
Hull material |
Steel |
|
Watertight bulkheads |
4 |
|
Number of decks |
7 |
|
Main engine |
1x MAN-B&W/HHI 7S60MC - 2 stroke 7 cylinder 600 x 2.400 mm combustion engine 14.280 / 19.415 bhp at 105,0 rpm Build: 03/2008 Manufacturer: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary water tube boiler - 8,8 bar 2x Economizer EGE boiler - 11,8 bar Heating surface: 249 m² Build: 03/2008 Manufacturer: Kang Rim Ind. Co., Ltd., Changzhou - China |
|
Generators |
3x MAN 6L28/32H main diesel generatorsets 1.750 kVA - 450 Volt |
|
Emergency generator |
1x AGCO Sisu Power, GenPowex 634 generatorset |
|
Bow thruster |
2.000 kW |
|
Number of cars |
8.011 |
|
Tank capacities |
Fuel oil: 5.277,8 m³ Fresh water: 323,8 m³ Water ballast: 7.509,4 m³ |
|
Anchor equipment |
Length: 687,50 m Diameter: 84 mm |
|
Manager |
Eukor Car Carriers Inc. Seoul |
|
Technical manager |
Wilhelmsen Ship Management (Korea) Ltd. |
|
Registered owner |
Lisa International Maritime S.A. |
|
Latest data adjustment |
20 November 2023 |
