Westerschelde 24 June 2019 |
 |
 |
|
| Westerschelde 12/08/19 | Westerschelde 12/08/19 |
|
Name |
SM VANCOUVER |
|
Previous names |
2000 - 02/2006 P&O Nedlloyd Mercator 02/2006 - 04/2015 Nedlloyd Mercator 04/2015 - 06/2017 Fleur |
|
Type |
Cellular containership - Panamax |
|
IMO-number |
9189495 |
|
Call sign |
D5IL2 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
03-2003 - 03/2015 The Netherlands, Rotterdam - Call sign: PCIM |
|
GT |
66.526 t |
|
DWT |
Summer: 67.712 t |
|
NT |
29.460 t |
|
Number of 20ft containers |
5.618 |
|
Container capacity 14t |
4.624 |
|
Reefer points |
500 |
|
Length |
278,01 m overall 264,40 m between perpendiculars |
|
Breadth |
40,00 m |
|
Draught |
Max: 14,00 m |
|
Depth |
24,40 m moulded |
|
Speed |
Max: 25,3 knots |
|
Built |
2000 |
|
Keel laid |
26/05/1999 |
|
Launch date |
05/12/1999 |
|
Delivery date |
24/03/2000 |
|
Builder |
Aker MTW Werft GmbH Wismar Germany |
|
Yard number |
001 |
|
Hull material |
Steel |
|
Hull type |
Single hull, double bottom |
|
Bulkheads |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai 10RTA96C - 2 stroke single acting 10 cylinder 960 x 2.500 mm combustion engine74.642 hp / 54.900 kW at 99,0 rpm Manufacturer: Hyundai Heavy Industries Co. Ltd., Ulsan - South Korea |
|
Propellers |
1x Screw propeller solid - aft at 99,0 rpm |
|
Boilers |
1x CHF 114,10 m² - 10,0 bar 1x CHR 648,00 m² - 13,0 bar |
|
Shaft generator |
1x 3000 kVA - 2400 kW |
|
Generators |
4x MaK 8M25 main diesel generatorsets each 2.900 kVA - 2.320 kW - 3.152 hp |
|
Emergency generator |
1x Diesel generatorset 412 kVA - 330 kW - 448 hp |
|
Bow thruster |
2.000 kW |
|
Number of holds |
8 |
|
Cargo hold capacity |
126.120 m³ |
|
Tank capacities |
Ballast: 21.384 t Fresh water: 597,0 t Fuel oil: 8.912 t Lube oil: 647,4 t |
|
Lifting equipment |
1x Crane - SWL 12,5 t 1x Crane - SWL 4,0 t 1x Crane - SWL 4,0 t 1x Crane - SWL 12,0 t |
|
Cargo gear |
Gearless |
|
Crew size |
17 |
|
Manager |
Korea Shipping Corp. Seoul South Korea |
|
Previous managers |
03/2000 - 01/2005 P&O Nedlloyd B.V., Rotterdam - The Netherlands 01/2005 - 02/2006 Blue Star Shipmanagement B.V., Rotterdam - The Netherlands 02/2006 - 03/2015 Maersk Ship Management B.V., Rotterdam - The Netherlands 03/2015 - 06/2017 Technomar Shipping Inc., Athens - Greece |
|
Registered owner |
KSC 601 Maritime SA Seoul South Korea |
|
Previous owners |
03/2000 - 10/2007 Halifax Asset Finance Ltd. 10/2007 - 03/2015 Bank Of Scotland Structured Asset Finance Ltd., Rotterdam - The Netherlands 03/2015 - 06/2017 Mercator Marine LLC, Athens - Greece |
|
Scrapped |
16/07/20 Beached at Gadani - Pakistan |
|
Latest data adjustment |
16 August 2020 |
