Westerschelde 16 March 2020 |
 |
 |
|
| Westerschelde 01/06/20 | Westerschelde 19/02/20 | |
|
Name |
E.R. VANCOUVER |
|
Previous names |
2004 - 2004 COSCO Vancouver 2004 - 2013 E.R. Vancouver 2013 - 2016 MSC Vancouver |
|
Type |
Cellular containership |
|
IMO-number |
9285691 |
|
Call sign |
D5VS7 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2004 - 2014 Liberia, Monrovia - Call sign: A8EO8 2014 - 2019 G.D. Luxembourg, Luxembourg City - Call sign: LXVQ |
|
GT |
83.133 t |
|
DWT |
Summer: 93.638 t |
|
NT |
51.532 t |
|
Number of 20ft containers |
7.455 |
|
Container capacity 14t |
5.650 |
|
Reefer capacity |
500 |
|
Length |
300,06 m overall 286,00 m between perpendiculars 287,25 m registered |
|
Breadth |
42,80 m extreme |
|
Draught |
14,50 m |
|
Forecastle |
14,10 m |
|
Depth |
20,23 m |
|
Speed |
Max: 24,0 knots |
|
Built |
2004 |
|
Keel laid |
08/06/2004 |
|
Launch date |
31/08/2004 |
|
Date of completion |
05/11/2004 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
H1545 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x HHI/Sulzer 12RTA96C-B - 2 stroke 12 cylinder 960 x 2.500 mm combustion engine 68.640 kW at 102,0 rpm Build: 2004 Manufacturer: Hyundai Heavy Industries Co., Ltd. Transmission: Main propulsion acts directly on the propellershaft Starter type: Compressed air direct |
|
Propellers |
1x Solid propeller (keyless) - aft at 102,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 10,0 bar Heating surface: 55.0 m² 1x Steam boiler, exhaust gas heated - 10,0 bar Heating surface: 641,0 m² Build: 2004 Manufacturer: Alfa Laval Qingdao Ltd. |
|
Electric installations |
1x Plant 450/230 V - 2.494 kVA 1x Plant 450/230 V - 2.494 kVA 1x Plant 450/230 V - 3.206 kVA 1x Plant 450/230 V - 3.206 kVA 1x Plant 450 V - 525 kVA 2x Plants each 24 V - 24 Ah 8x Plants each 24 V - 96 Ah 12x Plants each 24 V - 200 Ah |
|
Generators |
2x MAN 7L27/38 main diesel generatorsets each 2.494 kVA 2x MAN 9L27/38 main diesel generatorsets each 3.206 kVA |
|
Emergency & harbour gen. |
1x KTA 19-D(M) diesel generatorset 525 kVA |
|
Compressed air receivers |
2x Receivers each 16.800 litres - 30,0 bar 1x Receiver 250 litres - 30 bar 1x Receiver 150 litres - 30 bar 1x Receiver 250 litres - 8,8 bar |
|
Bow thruster |
1x Transverse thruster 2.500 kW, forward |
|
Tank capacities |
Ballast: 21.916,2 m³ |
|
Anchor equipment |
3x Anchors weight each 17.800 kg Length: 742,50 m Diameter: 102 mm |
|
Crew size |
31 |
|
Manager |
ZEABORN Ship Management GmbH & Cie. KG Ludwig-Erhard-Strasse 22 20459 Hamburg Germany |
|
Registered owner |
MS "E.R. VANCOUVER" Schiffahrtsgesellschaft mbH & Co. KG |
|
Renamed |
2021 MSC Vancouver Liberia, Monrovia - Call sign: D5VS7 Owner: Vancouver Shipping Limited, Limassol - Cyprus Manager: MSC Shipmanagement Limited, Limassol - Cyprus |
|
Latest data adjustment |
23 February 2023 |
