| Westertschelde 10 April 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 10/04/18 | Westerschelde 03/01/16 | Westerschelde 03/01/16 | Westerschelde 11/04/18 | Westerschelde 11/04/18 | WS 11/04/18 | |||||
|
Name |
MSC CLARA |
|
Type |
Cellular containership - Post-Panamax |
|
IMO-number |
9708693 |
|
Classification |
DNV |
|
Call sign |
3FZW9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
192.237 t |
|
DWT |
Summer: 199.272,7 t |
|
NT |
111.423 t |
|
Number of 20ft containers |
On deck: 11.258 In hold: 7.966 Total: 19.224 |
|
Container capacity 14t |
13.500 |
|
Reefer capacity |
1.800 |
|
Length |
395,50 m overall 379,41 m between perpendiculars |
|
Breadth |
59,08 m extreme |
|
Draught |
Summer: 16,00 m |
|
Depth |
30,30 m moulded |
|
Deckhouse |
6,40 m |
|
Bridge |
372,02 m |
|
Freeboard |
6.479 mm |
|
Speed |
Max: 22,8 knots Service: 19,0 knots |
|
Built |
2015 |
|
Keel laid |
30/12/2014 |
|
Launch date |
21/08/2015 |
|
Date of completion |
12/11/2015 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. Okpo Shipyard South Korea |
|
Yard number |
4282 |
|
Hull material |
Steel |
|
Bulkheads |
13 |
|
Number of decks |
2x Upper deck / 2nd deck |
|
Main engine |
1x MAN-B&W 11S90ME-C 10.2 - 2 stroke 11 cylinder 900 x 3.260 mm combustion engine 62.500 kW / 84.975 hp at 82,0 rpm Manufacturer: Hyundai Heavy Industries Co., Ltd. - South Korea |
|
Propellers |
1x Fixed pitch single five-blade propeller - aft at 82,2 rpm Diameter: 10,50 m |
|
Boilers |
3x Auxiliary boiler, exhaust gas heated 1x Auxiliary boiler, oil/gas fired |
|
Generators |
2x MAN-B&W 8L32/40 - 4 stroke 8 cylinder 320 x 400 combustion engine each 4.000 kW connected with 2 generators each 3.900 ekW 2x MAN-B&W 9L32/40 - 4 stroke 9 cylinder 320 x 400 combustion engine each 4.500 kW connected with 2 generators each 4.000 ekW |
|
Emergency generator |
1x MAN D2842LE201 diesel generatorset |
|
Bow thruster |
2x Tunnel thruster each 2.500 kW / 3.399 bhp, forward |
|
Number of holds |
11 |
|
Tank capacities |
Ballast: 33.572,2 m³ |
|
Anchor equipment |
Length: 770,00 m Diameter: 132 mm |
|
Cargo gear |
Gearless |
|
ISM & commercial manager |
Mediterranean Shipping Company S.r.l. Via Francesco Ciampa 29 80063 Piano di Sorrento NA Italy |
|
Registered owner |
Ocean Triumph Shipping Ltd. Care of MSC Mediterranean Shipping Co., SA chemin Rieu, 12-14 1208 Geneva Switzerland |
|
Latest data adjustment |
11 January 2023 |
