| Westerschelde 17 April 2017 |
|
Name |
SEAMAX NORWALK |
|
Previous names |
2005 - 06/2017 Hanjin Boston |
|
Type |
Cellular containership - Panamax Carriage of dangerous goods |
|
IMO-number |
9290464 |
|
Call sign |
V7VT5 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
2005 - 2016 Germany - Call sign: DDZK2 2016 - 2016 Portugal - Call sign: CQYH |
|
GT |
82.794 t Suez: 87.251,28 t |
|
DWT |
93.541,7 t |
|
NT |
48.047 t Suez: 76.262,16 t |
|
Displacement |
122.833 t |
|
Number of 20ft containers |
In hold: 3.500 On deck: 3.971 Total: 7.471 |
|
Container capacity 14t |
5.650 |
|
Reefer capacity |
500 |
|
Length |
299,89 m overall 286,00 m between perpendiculars |
|
Breadth |
42,80 m moulded |
|
Draught |
Summer: 14,50 m |
|
Freeboard |
Summer: 5.749 mm |
|
Depth |
24,60 m moulded |
|
Speed |
Max: 24,0 knots |
|
Built |
2005 |
|
Keel laid |
02/02/2005 |
|
Delivery date |
30/06/2005 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. 1, Cheonha-Dong Dong-Ku Ulsan South Korea |
|
Yard number |
H1580 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 12K98MC-C - 2 stroke single acting 12 cylinder 980 x 2.400 mm combustion engine Mcr 68.490 kW / 93.119 hp at 104,0 rpm Builder: Hyundai Heavy Industries Co., Ltd. - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 140,0 rpm |
|
Boilers |
1x Exhaust gas economizer - 9,0 MPa 1x Vertical Auxiliary oil fired boiler - 9,0 MPa |
|
Generators |
2x MAN-B&W 7L27/38 - 4 stroke 7 cylinder 270 x 380 mm diesel engines each Mcr 2.280 kW connected with generators each 1.995 kW - 450/230 Volt 60 Hz 2x MAN-B&W 79L27/38 - 4 stroke 9 cylinder 270 x 380 mm diesel engines each Mcr 3.060 kW connected with generators each 2.565 kW - 450/230 Volt 60 Hz |
|
Bow thruster |
1x Controllable pitch propeller 2.500 kW / 3.399 bhp, forward |
|
Tank capacities |
Fresh water: 594,0 m³ Diesel oil: 512,8 m³ Fuel oil: 10.602,0 m³ Lub oil: 622,0 m³ Ballast: 24.140,1 m³ |
|
Lifting equipment |
1x Monorail hoist crane - SWL 12,5 t 1x Engine room overhead crane - SWL 12,5 t Manufacturer: Fuchs Fordertechnik 1x Hose handling davit port - SWL 4,0 t 1x Hose handling davit starboard - SWL 4,0 t Manufacturer: Oriental Precision & Engineering Co., Ltd. |
|
Cargo gear |
Gearless |
|
Crew size |
19 |
|
Commercial manager |
MC-Seamax Management LLC 6th Floor, 6, Landmark Square Stamford CT 06901-2704 USA |
|
ISM manager |
Fleet Ship Management Pte Ltd. 31-01, MTower, 460, Alexandra Road Singapore 119963 republic of Singapore |
|
Registered owner |
Lanyard LLC Care of MC-Seamax Management LLC 6th Floor, 6, Landmark Square Stamford CT 06901-2704 USA |
|
Latest data adjustment |
14 March 2023 |
