| Westerschelde 17 April 2016 |
|
Name |
SAGITTA |
|
Previous names |
2009 build as: Frisia Brussel |
|
Type |
Cellular containership - Carriage of dangerous goods Panamax |
|
IMO-number |
9401166 |
|
Call sign |
V7UO5 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
2010 Germany |
|
GT |
36.519 t Suez: 38.313,42 t |
|
DWT |
42.614 t |
|
NT |
15.774 t Panama: 32.505 t Suez: 33.134,13 t |
|
Number of 20ft containers |
Deck: 2.028 Holds: 1.398 Total: 3.426 |
|
Number of 40ft containers |
Deck: 1,006 units 40’ + 16 units 20’ Hold: 688 units 40’ + 22 units 20’ Total: 1.694 units 40’ + 38 units 20’ |
|
Container capacity 14t |
2.410 |
|
Reefer sockets |
500 whereof 108 in holds |
|
Length |
228,50 m overall 220,23 m between perpendiculars |
|
Breadth |
32,00 m |
|
Draught |
Summer: 12,00 m |
|
Freeboard |
6.580 mm |
|
Depth |
18,55 m moulded |
|
Speed |
Max: 23,0 knots |
|
Built |
2010 |
|
Keel laid |
31/07/2008 |
|
Launch date |
27/03/2009 |
|
Delivery date |
18/06/2010 |
|
Builder |
Thyssen Nordseewerke GmbH Nordseewerke Emden Shipyard GmbH Zum Zungenkai D-26725 Emden Germany |
|
Yard number |
558 |
|
Hull material |
Steel |
|
Hull type |
Single hull, double bottom |
|
Bulkheads |
8 |
|
Main engine |
1x MAN-B&W 8K80MC-C - 2 stroke 8 cylinder combustion engine 28.880 kW at 104,0 rpm Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller 5 blades |
|
Boilers |
1x Composite boiler |
|
Generators |
2x MaK 8M25 main diesel generatorsets each 2.224 kW at 720 rpm 1x MaK 6M25 main diesel generatorsets each 1.720 kW at 720 rpm |
|
Emergency generator |
1x MAN D2866 diesel generatorset 280 kW at 1.800 rpm |
|
Bow thruster |
1x Electrically driven thruster 1.200 kW |
|
Number of hatches |
11 Hatch 1-2: 12,64 m × 22,96 m, 2 covers Hatch 3 - 11: 12,64 m × 28,15 m, 3 covers |
|
Tank capacities |
Diesel oil: 219,08 m³ Fuel oil: 4.885,83 m³ Lub oil: 215,58 m³ Ballast: 7.829,33 m³ |
|
Crew size |
23 |
|
Manager |
Unitized Ocean Transport Imittou 7 Paleo Faliro 175 64 Greece |
|
Registered owner |
Diana Shipping Inc. c/o Diana Shipping Services S.A. Pendelis 16 175 64 Palaio Faliro Athens Greece |
|
Sister ships |
CSAV Romeral Box Voyager Elbspirit |
|
Renamed |
2021 MSC Sagitta III Portugal, Madeira - Call sign: CQEU2 Owner: Sagitta Shipping & Trading Ltd. Operator: MSC - Mediterranean Shipping Company |
|
Latest data adjustment |
12 July 2023 |
