Westerschelde 18 August 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 18/08/18 | Westerschelde 18/08/18 | Antwerpen 10/09/16 | Antwerpen 23/12/16 | Westerschelde 02/02/19 | Westerschelde 19/01/18 | |||||
|
Name |
MAERSK NOTTINGHAM |
|
Previous names |
2003 Launch as: Regina Star 2004 - 01/2006 P&O Nedlloyd Regina |
|
Type |
Cellular containership |
|
IMO-number |
9275050 |
|
Call sign |
A8DH2 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
26.833 t |
|
DWT |
Summer: 34.300,6 t |
|
NT |
12.743 t |
|
Number of 20ft containers |
2.556 |
|
Container capacity 14t |
1.850 |
|
Reefer capacity |
600 |
|
Length |
210,06 m overall 199,00 m between perpendiculars |
|
Breadth |
30,23 m extreme |
|
Draught |
11,50 m |
|
Keel to mast end |
51,98 m |
|
Forecastle |
5.240 mm |
|
Depth |
16,70 m |
|
Speed |
Max.: 22,0 knots |
|
Built |
2004 |
|
Keel laid |
19/08/2003 |
|
Launch date |
08/11/2003 |
|
Date of completion |
08/01/2004 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. 1, Cheonha-dong, Dong-gu Ulsan, Kyongsang-namdo Republic of Korea |
|
Yard number |
H1488 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 7RTA72U-B - 2 stroke 7 cylinder 720 x 2.500 mm combustion engine 21.560 kW / 29.313 hp at 99,0 rpm Year of manufacture: 2008 Manufacturer: Hyundai Engine & Machinery Co., Ltd., Ulsan - Republic of Korea |
|
Propellers |
1x Solid propeller (keyless) - aft at 99,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 8,0 bar Heating surface: 35,0 m² 1x Steam boiler, exhaust gas heated - 8,0 bar Heating surface: 392,9 m² |
|
Bow thruster |
1x 1.000 kW |
|
Generators |
4x MAN-B&W 8L28/32H diesel generatorsets each 1.600 kW Manufacturer: MAN B&W Diesel A/S Holeby Diesel |
|
Emergency generator |
1x MAN D2866 TE diesel generatorset 230 kVA |
|
Batteries |
12x Batteries for UPS navigation each 300 Ah 12x Batteries for emergency lighting each 200 Ah 2x Batteries for start emergency engine each 200 Ah 2x Batteries for automation each 200 Ah |
|
Compressed air receivers |
2x Receivers each 5.000 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar 1x Receiver 200 litres - 8,8 bar 1x Receiver 2.000 litres - 8,0 bar |
|
Bow thruster |
1x Transverse thruster 1.000 kW, forward |
|
Tank capacities |
Ballast: 9.457 m³ |
|
Anchor equipment |
3x Anchors weight each 9.300 kg Length: 660,00 m Diameter: 76 mm |
|
Cargo gear |
4x Deck cranes - SWL 40,0 t each |
|
Manager |
ZEABORN Ship Management GmbH & Cie. KG Ludwig-Erhard-Straße 22 20459 Hamburg Germany |
|
Previous manager |
E.R. Schiffahrt GmbH & Cie. KG - Germany |
|
Operator |
Maersk Line |
|
Registered owner |
Bomar B LLC |
|
Previous names & owners |
2003 - 2004 Regina Star - Regina Star, Hamburg - Germany 2004 - 01/2006 P&O Nedlloyd Regina - P&O Nedlloyd Ltd, London- United Kingdom |
|
Renamed |
2019 Bomar Regina Liberia, Monrovia - Call sign: A8DH2 Owner: Borealis Maritime, London - United Kingdom Manager: Bernhard Schulte Shipmanagement (Deutschland) GmbH & Co. KG 09/2022 CMA CGM Puerto Antioquia The Bahamas, Nassau - Call sign: C6GD7 Owner: CMA CGM S.A. Manager: Bernhard Schulte Shipmanagement (Deutschland) GmbH & Co. KG |
|
Latest data adjustment |
20 June 2023 |
