| Westerschelde 31 August 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 30/03/17 | Westerschelde 20/10/13 | Westerschelde 05/03/015 | Westerschelde 11/04/16 | Westerschelde 23/07/15 | Westerschelde 21/02/17 | |||||
|
Name |
MSC TOKYO |
|
Previous names |
2005 - 2005 Santa Vanessa |
|
Type |
Cellular containership |
|
IMO-number |
9295361 |
|
Call sign |
A8JM6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
65.483 |
|
DWT |
Summer: 71.949 t |
|
NT |
37.611 |
|
Light ship |
23.963 t |
|
Number of 20ft containers |
5.599 |
|
Container capacity 14t |
4.410 |
|
Reefer capacity |
390 |
|
Length |
274,68 m overall 264,96 m registered |
|
Breadth |
40,00 m registered |
|
Draught |
14,50 m |
|
Keel to mast end |
62,09 m |
|
Forecastle |
132,48 m |
|
Bridge |
118,66 m |
|
Freeboard |
5.680 mm |
|
Depth |
24,20 m moulded |
|
Speed |
26,1 knots |
|
Built |
2005 |
|
Keel laid |
21/02/2005 |
|
Launch date |
06/05/2005 |
|
Date of completion |
28/06/2005 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. 93, Daebul-ro, Samho-eup Yeongam-gun Jeollanam-do ,526-701 Republic of Korea |
|
Yard number |
S228 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
2 |
|
Main engine |
1x Hyundai MAN-B&W 10K98MC-C - 2 stroke 10 cylinder 980 x 2.400 mm combustion engine 57.100 kW / 77.634 hp at 104,0 rpm Year of manufacture: 2005 Manufacturer: Hyundai Heavy Industries Co., Ltd. 1, Jeonha-dong, Dong-gu Ulsan, 682-792 Kyongsang-namdo Republic of Korea |
|
Propellers |
1x Solid mono-block propeller (keyless) - aft 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 10,0 bar Heating surface: 40,1 m² 1x Steam boiler, exhaust gas heated - 10,0 bar Heating surface: 914,0 m² Year of manufacture: 2004 Manufacturer: Alfa Laval Qingdao Ltd. 86 Guangzhou Road North Jiaozhou Qingdao, 266300 Shandong People's Republic of China |
|
Electric installations |
4x Plants each 440/ 230 V - 2.493,8 kVA 1x Plant 440 V - 625 kVA 1x Plant 12 V - 20 Ah 1x Plant 12 V - 60 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 500 Ah |
|
Generators |
4x MAN 7L27/38 main diesel generatorsets each 2.493,8 kVA / 1.995 kW |
|
Emergency generator |
1x Cummins VTA-28-D(M) diesel generatorset 625 kVA |
|
Batteries |
12x Batteries for emergency lighting each 200 Ah |
|
Compressed air receivers |
2x Receivers each 22.000 litres - 30,0 bar 2x Receivers each 250 litres - 30,0 bar 1x Receiver 200 litres - 7,7 bar |
|
Bow thruster |
1x Transverse thruster 2.500 kW, forward |
|
Anchor equipment |
3x Anchors weight each 16.100 kg Chain length: 742,50 m Diameter: 97 mm |
|
Cargo gear |
Gearless |
|
Manager |
Reederei Claus-Peter Offen GmbH & Co. KG Bleichenbrücke 10 20354 Hamburg Federal Republic of Germany |
|
Operator |
MSC - Mediterranean Shipping Company S.A. |
|
Registered owner |
Beteiligungsgesellschaft MS "SANTA VANESSA" GmbH & Co. KG Bleichenbrücke 10 20354 Hamburg Federal Republic of Germany |
|
Renamed |
05/2017 Santa Venessa Liberia, Monrovia – Call sign: A8JM6 Owner: Beteiligungsgesellschaft MS "SANTA VANESSA" GmbH & Co. KG Manager: CPO Containerschiffreederei (GmbH & Co.) KG |
|
Last update |
26 April 2024 |
