Westerschelde 23 April 2014 |
|
Name |
HS CHOPIN |
|
Type |
Cellular containership |
|
IMO-number |
9323027 |
|
Call sign |
A8ND7 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
38.320 t |
|
DWT |
Summer: 46.344 t |
|
NT |
21.924 t |
|
Number of 20ft containers |
3.768 |
|
Number of 40ft containers |
500 |
|
Container capacity 14t |
2.501 |
|
Reefer capacity |
625 |
|
Length |
246,86 m overall 233,27 m registered |
|
Breadth |
32,20 m registered |
|
Draught |
12,30 m |
|
Forecastle |
116,63 m |
|
Bridge |
108,83 m |
|
Depth |
19,30 m moulded |
|
Speed |
23,4 knots |
|
Built |
2007 |
|
Keel laid |
12.05.2007 |
|
Launch date |
17.07.2007 |
|
Date of completion |
02.10.2007 |
|
Builder |
STX Offshore & Shipbuilding Co., Ltd. |
|
Yard number |
S1214 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 9K80MC-C - 2 stroke 9 cylinder 800 x 2.300 mm diesel engine - 32.490 kW at 104,0 rpm Year of manufacture: 2007 Manufacturer: STX Engine Co., Ltd. |
|
Propellers |
1x Solid propeller (keyless) - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 8,83 bar Heating surface: 36,1 m² 1x Steam boiler, exhaust gas heated - 8,83 bar Heating surface: 650,6 m² Year of manufacture: 2007 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) |
|
Electric installations |
4x Plants each 450 V - 2.250 kVA 1x Plant 450 V - 225 kVA 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah |
|
Generators |
4x Main diesel generatorsets each 2.250 kVA |
|
Emergency generator |
1x Diesel generatorset 225 kVA |
|
Batteries |
1x Battery for UPS navigation 200 Ah 1x Battery for UPS radio 200 Ah |
|
Compressed air receivers |
2x Receivers each 9.000 litres - 30,0 bar 1x Receiver 350 litres - 30,0 bar 1x Receiver 1.500 litres - 7,0 bar 1x Receiver 140 litres - 7,0 bar |
|
Bow thruster |
1x Transverse thruster 1.400 kW, forward |
|
Anchor equipment |
3x Anchors weight each 11.100 kg Chain length: 687,50 m |
|
Cargo gear |
Gearless |
|
Crew size |
26 |
|
Manager |
Hansa Shipping GmbH & Co. KG |
|
Registered owner |
Schiffahrts-Gesellschaft "HS CHOPIN" mbH & Co. KG |
|
Latest data adjustment |
15 March 2015 |
