Name |
MSC EVA |
|
Type |
Cellular containership |
|
IMO-number |
9401130 |
|
Call sign |
3EVM7 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
151.559 t |
|
DWT |
Summer: 162.867 t |
|
NT |
83.151 t |
|
Number of 20ft containers |
13.798 |
|
Container capacity 14t |
10.500 |
|
Reefer capacity |
1.000 |
|
Length |
366,06 m overall 351,60 m registered |
|
Breadth |
51,20 m registered |
|
Draught |
15,60 m |
|
Forecastle |
175,04 m |
|
Bridge |
164,84 m |
|
Poop |
20,02 m |
|
Depth |
29,90 m moulded |
|
Speed |
Max.: 24,1 knots |
|
Built |
2010 |
|
Keel laid |
28/09/2009 |
|
Launch date |
12/12/2009 |
|
Date of completion |
16/09/2010 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje Shipyard 530, Jangpyeong-ri, Sinhyeon-eup Geoje, 656-710 Kyongsang-namdo Republic of Korea |
|
Yard number |
1714 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 12K98MC-C Mk7 - 2 stroke 12 cylinder 980 x 2.400 mm diesel engine - 72.240 kW at 104,0 rpm Year of manufacture: 2009 Manufacturer: Doosan Engine Co., Ltd. 18, Gongdanro21-gil, Sungsan-gu Changwon Republic of Korea |
|
Propellers |
1x Solid propeller (Keyless) - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,81 bar Heating surface: 76,0 m² 1x Steam boiler, exhaust gas heated - 9,81 bar Heating surface: 1.204,0 m² Year of manufacture: 2009 Manufacturer: KangRim Heavy Industries Co., Ltd. 40, Wongnam-dong Changwon Republic of Korea |
|
Electric installations |
4x Plants each 6.600 V - 4.225 kVA 1x Plant 450 V - 625 kVA 3x Plants each24 V - 36 Ah 1x Plant 24 V - 92 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 215 Ah 1x Plant 24 V - 300 Ah 2x Plants each110 V - 360 Ah |
|
Generators |
4x MAN-B&W 7L32/40 main diesel generatorsets each 4.225 kVA / 3.380 kW |
|
Emergency generator |
1x Diesel generatorset 625 kVA |
|
Batteries |
2x Batteries for automation each 360 Ah 1x Battery for UPS navigation 300 Ah 1x Battery for start emergency engine 215 Ah 1x Battery for UPS radio 200 Ah 1x Battery for automation 92 Ah 3x Batteries for automation each 36 Ah |
|
Compressed air receivers |
2x Receivers each 16.500 litres - 30,0 bar 1x Receiver 300 litres - 30,0 bar 1x Receiver 250 litres - 7,0 bar |
|
Bow thruster |
2x Transverse thruster each 1.700 kW, forward |
|
Anchor equipment |
3x Anchors weight each 24.500 kg Chain length: 770,00 m |
|
Cargo gear |
Gearless |
|
Crew size |
34 |
|
Manager |
MSC Mediterranean Shipping Company S.r.l. Via Francesco Ciampa, 29 80063 Piano di Sorrento Naples Italy |
|
Operator |
MSC - Mediterranean Shipping Company |
|
Registered owner |
Compania Naviera Eva S.A. Calle 50, Edificio Universal 50 Planta Baja Panama City Republic of Panama |
|
Latest data adjustment |
11 March 2020 |
