Westerschelde 07 June 2014 |
 |
 |
 |
 |
 |
||||
| Westerschelde 07/06/14 | Westerschelde 20/01/17 | Westerschelde 24/10/15 | Westerschelde 24/04/19 | Westerschelde 24/12/16 |
|
Name |
HANSA ASIA |
|
Previous names |
1012 Launch as: Asia |
|
Type |
Cellular containership - Panamax |
|
IMO-number |
9459400 |
|
Call sign |
V7ZY6 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flag |
2012 - 2014 Liberia, Monrovia 2014 - 2018 Germany, Hamburg - Call sign: DFPY2 |
|
GT |
38.388 t |
|
DWT |
Summer: 47.115 t |
|
NT |
16.631 t |
|
Number of 20ft containers |
In hold: 1.460 On deck: 2.175 Total: 3.635 |
|
Container capacity 14t |
2.373 |
|
Reefer capacity |
550 |
|
Length |
239,59 m overall 226,57 m registered |
|
Breadth |
32,00 m registered |
|
Draught |
12,50 m |
|
Keel to mast end |
54,44 m |
|
Depth |
19,20 m moulded |
|
Speed |
23,4 knots |
|
Built |
2012 |
|
Keel laid |
27/12/2010 |
|
Launch date |
05/08/2012 |
|
Date of completion |
12/2012 |
|
Builder |
Shanghai Shipyard Co., Ltd. 3F No. 10 Building 468, Yangshupu Road Yangpu District Shanghai People's Republic of China |
|
Yard number |
S1159 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 7K90MC-C9 - 2 stoke single acting 7 cylinder 800 x 2.600 mm combustion engine 31.710 kW / 43.113 hp at 104,0 rpm Year of manufacture: 2011 Manufacturer: Hyundai Heavy Industries Co., Ltd. Engine & Machinery Division 1000 Bangeojinsunhwan-doro Dong-gu Ulsan Republic of Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 90, bar Heating surface: 20,0 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 451,8 m² Year of manufacture: 2011 Manufacturer: Saacke VKK Marine Boilers GmbH Kaiserstr. 4 24143 Kiel Federal Republic of Germany |
|
Electric installations |
4x Plants each 450 V - 2.250 kVA 1x Plant 450 V - 212,5 kVA 2x Plants each 24 V - 2 Ah 2x Plants each 24 V - 7 Ah 1x Plant 24 V - 12 Ah 2x Plants each 24 V - 65 Ah 1x Plant 24 V - 70 Ah 2x Plants each 24 V - 70 Ah 2x Plants each 24 V - 200 Ah 12x Plants each 24 V - 300 Ah 12x Plants each 24 V - 300 Ah |
|
Generators |
4x Hyundai-Himsen 7 H25/33 - 4 stroke 7 cylinder 250 x 330 mm combustion engines each 1.900 kW coupled with 4 generators 1.800 kW / 2.250 kVA 450 Volt |
|
Emergency generator |
1x Sisu Diesel 645 DSBIG diesel generatorset 212,5 kVA |
|
Batteries |
12x Batteries for other purpose each 300 Ah 12x Batteries for automation each 300 Ah 2x Batteries for UPS radio each 200 Ah 2x Batteries for start emergency engine each 70 Ah 1x Battery for other purpose 70 Ah 2x Batteries for diesel control each 65 Ah 1x Battery for automation 12 Ah 2x Batteries for other purpose each 7 Ah 2x Batteries for other purpose each 2 Ah |
|
Bow thruster |
1x Transverse thruster 1.200 kW / 1.632 bhp, forward |
|
Tank capacities |
Ballast: 16.734,9 m³ |
|
Anchor equipment |
3x Anchors weight each 11.700 kg Chain Length: 687,50 m Diameter: 84 mm |
|
Cargo gear |
4x Cranes - SWL 45,0 t each |
|
Crew size |
20 |
|
Manager |
Leonhardt & Blumberg Reederei GmbH & Co. KG Neumühlen 13 22763 Hamburg Federal Republic of Germany |
|
Registered owner |
Hansa Flottbek Feeder IV Care of Leonhardt & Blumberg Schiffahrtsgesellschaft mbH & Co KG Neumuehlen 13 22763 Hamburg Germany |
|
Previous owner |
Schiffahrts-Gesellschaft "ASIA" mbH & Co. KG Neumühlen 13 22763 Hamburg Federal Republic of Germany |
|
Latest data adjustment |
25 August 2021 |
