Westerschelde 24 February 2017 |
 |
 |
 |
 |
|||
| Westerschelde 24/02/17 | Westerschelde 04/01/17 | Westerschelde 04/01/17 | Westerschelde 07/08/15 | |||
|
Name |
CMA CGM AMAZON |
|
Previous names |
Built as: Akadimos 2015 - 06/2020 CMA CGM Amazon 6/2020 - 02/2024 Akadimos |
|
Type |
Cellular containership |
|
IMO-number |
9706308 |
|
Call sign |
9HA5144 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
Liberia, Monrovia - Call sign: D5IS5 |
|
GT |
96.424 Suez: 99.615,89 |
|
DWT |
Summer: 115.534,4 t |
|
NT |
59.714 Suez: 85.710,29 |
|
Displacement |
146.354,7 t |
|
Number of 20ft containers |
On Deck (9 tiers): 5.420 In Holds (9 tiers): 3.742 Total: 9.162 |
|
Container capacity 14t |
7.580 |
|
Reefer capacity |
On deck: 1.000 In hold: 500 Total: 1.500 |
|
Length |
299,99 m overall 288,29 m between perpendiculars |
|
Breadth |
48,40 m moulded |
|
Draught |
Max.: 14,50 m |
|
Air draft |
62,00 m |
|
Freeboard |
5.000 mm |
|
Depth |
24,80 m to main deck |
|
Speed |
23,3 knots |
|
Built |
2015 |
|
Keel laid |
15/11/2014 |
|
Launch date |
19/01/2015 |
|
Delivery date |
10/06/2015 |
|
Builder |
Daewoo Mangalia Heavy Industries SA 1, Portului Street Mangalia Constanta, 905500 Romania |
|
Yard number |
4095 |
|
Hull material |
Steel |
|
Main engine |
1x Wärtsilä/Sulzer W9X82 - 2 stroke 9 cylinder combustion engine Mcr 37.200 kW / 50.577 hp at 80,0 rpm Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Fired boiler Mission OS TCi - 9,0 MPa 1x Unfired exhaust gas boiler Mission XW-TG - 10,0 MPa |
|
Generators |
3x Diesel generatorsets each 4.300 kW 1x Diesel generatorset 2.800 kW |
|
Bow thruster |
1x 3.000 kW |
|
Tank capacities |
Ballast: 33/566,60 m³ Fuel oil: 9.082,00 m³ Lub oil: 516,50 m³ Diesel oil: 723,40 m³ fresh water: 522,00 m³ |
|
Lifting equipment |
2x Engine room double jig cranes - SWL 6,3 t each 1x Monorail crane - SWL 12,5 t |
|
Cargo gear |
Gearless |
|
Crew |
29 |
|
Manager |
CMA CGM - Compagnie Maritime D'Affrètement - Compagnie Générale Maritime Marseille France |
|
Registered owner |
Hai Kuo Shipping 1987c Limited |
|
Latest data adjustment |
12 December 2024 |
