Westerschelde 30 October 2015 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 30/10/15 | Westerschelde 26/05/16 | Westerschelde 23/12/16 | Westerschelde 23/12/16 | Westerschelde 30/09/19 | Westerschelde 30/09/19 |
|
Name |
YM WORTH |
|
Type |
Cellular containership |
|
IMO-number |
9704635 |
|
Call sign |
VROO6 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
144.651 t |
|
DWT |
145.401 t |
|
NT |
66.967 t |
|
Number of 20ft containers |
In hold: 6.166 On deck: 7.914 Total: 14.080 |
|
Number of 14 t container |
10.150 |
|
Reefer capacity |
1.000 |
|
Length |
368,08 m overall 352,00 m between perpendiculars |
|
Breadth |
51,05 m extreme |
|
Draught |
16,02 m |
|
Depth |
25,63 m |
|
Speed |
Max: 24,7 knots Service: 23,2 knots |
|
Built |
2015 |
|
Keel laid |
12/08/2015 |
|
Delivery date |
18/09/2015 |
|
Builder |
Hyundai Heavy Industries Ulsan South Korea |
|
Yard number |
2646 |
|
Hull material |
Higher tensile steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 11S90ME-C9.2 - 2 stroke single acting 11 cylinder 900 x 3.260 mm combustion engine Mcr 52.723 kW / 71.683 hp at 79,0 rpm Manufacturer: Hyundai Heavy Industries Co ., Ltd. - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 79,0 rpm |
|
Boilers |
1x Exhaust gas eEconomiser 1x Auxiliary boiler, oil/gas fired Manufacturer: KangRim Heavy Industries Co., Ltd. |
|
Generators |
2x Daihatsu 6DC32 - 6 cylinder diesel engine each Mcr 2.950 kW connected with generators each 2.800 ekW - 6.600 Volt 60 Hz 2x Daihatsu 8DC32 - 8 cylinder diesel engine each Mcr 3.900 kW connected with generators each 3.700 ekW - 6.600 Volt 60 Hz |
|
Emergency generator |
1x Doosan V/AD 158 diesel generatorset |
|
Bow thruster |
1x Controllable pitch thruster 1.500 kW / 2.039 bhp, forward 1x Fixed pitch thruster 1.500 kW / 2.039 bhp, forward |
|
Number of holds |
10 |
|
Tank capacities |
Ballast: 28.330,6 m³ |
|
Anchor equipment |
Length: 770,00 m Diameter: 127 mm |
|
Cargo gear |
Gearless |
|
Crew |
26 |
|
Manager |
Seaspan Shipmanagement Suite 2600, 200, Granville Street Vancouver BC V6C 1S4 Canada |
|
Operator |
Yang Ming Marine Transport Corporation Keelung Taiwa |
|
Registered owner |
GC Intermodal XII Ltd. |
|
Latest data adjustment |
20 July 2021 |
