Westerschelde 28 October 2015 |
 |
 |
|
| Westerschelde 28/10/15 | Westerschelde 04/10/17 |
|
Name |
COSCO DENMARK |
|
Type |
Cellular containership |
|
IMO-number |
9516478 |
|
Call sign |
VRNP8 |
|
Flag |
Hong Kong (Special Administrative Region of the People's Republic of China) |
|
Port of registry |
Hong Kong |
|
GT |
153.666 t registered Suez: 159.758,81 t |
|
DWT |
Summer: 156.694 t |
|
NT |
65.592 t registered Suez: 144.608,76 t |
|
Number of 20ft containers |
13.386 |
|
Container capacity 14t |
9.000 |
|
Length |
366,00 m overall 348,00 m between perpendiculars |
|
Breadth |
51,20 m moulded |
|
Draught |
Max.: 15,50 m |
|
Freeboard |
7.493 mm |
|
Depth |
29,85 m moulded |
|
Speed |
Max.: 24,3 knots |
|
Service |
NE3 - North Europe Service 3 |
|
Built |
2014 |
|
Keel laid |
07.11.2011 |
|
Launch date |
09.07.2014 |
|
Delivery date |
24.09.2014 |
|
Builder |
Cosco Nantong Shipyard KHI Ship Engineering Co., Ltd. |
|
Yard number |
NE118 |
|
Hull material |
High strength steel Forged steel |
|
Bulkheads |
Water tight: 14 Oil tight: 2 |
|
Main engine |
1x MAN-B&W-HHI 12K98ME7 - 2 stroke 12 cylinder 980 x 2.660 mm diesel engine 72.240 kW / 98.219 hp at 94,0 rpm Manufacturer: HHI Engine & Machinery Div. |
|
Propellers |
1x Fixed propeller - aft at 94,0 rpm Manufacturer: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Fired boiler Mission OM - 8,0 bar 1x Unfired exhaust gas boiler Mission XS-7V - 10,0 bar Manufacturer: Alfa Laval Qingdao Ltd. |
|
Generators |
2x HSJ7 809-10P diesel generatorsets each 3.000 kW 3x HSJ7 803-10P diesel generatorsets each 2.500 kW Manufacturer: HHI Electro Electric System |
|
Hold capacity |
325.414,3 m³ |
|
Tank capacities |
Ballast: 22 Sea Water: 14 Fuel Oil: 10 Lubricating Oil: 9 Diesel Oil: 3 Fresh Water: 3 Chain: 2 Waste Water: 2 Hydraulic Oil: 1 Sludge: 1 |
|
Tank capacities |
Diesel Oil: 739,8 m³ / 665,82 t Freshwater: 700,2 m³ Fuel Oil: 12.070,1 m³ 11.819,03 t Hydraulic Oil: 19,4 m³ Lube Oil: 819,6 m³ / 731,76 t Tank Ballast: 28.167.2 m³ / 28.871,38 t |
|
Lifting equipment |
1x Provision crane - SWL 4,0 t Manufacture: Nantong Sekigahara Machinery Manufacturing Co., Ltd. 1x Provision crane - SWL 1,5 t Manufacture: South China Marine Machinery Limited Corporation |
|
Cargo gear |
Gearless |
|
Manager |
COSCO Denmark Shipping Limited |
|
Operator |
COSCO Container Lines |
|
Registered owner |
COSCO Denmark Shipping Limited |
|
Latest data adjustment |
30 November 2015 |
