Westerschelde 18 November 2015 |
 |
 |
|
| Westerschelde 09/03/16 | Westerschelde 22/09/15 | |
|
Name |
MSC ANISHA R. |
|
Previous names |
2002 Launch as: Santa Rafaela 2002 - 02/2006 P&O Nedlloyd Remuera 02/2006 - 05/2007 Maersk Denia 05/2007 - 11/2009 Southampton Expresss 11/2009 - 2016 Santa Rafaela |
|
Type |
Cellular containership |
|
IMO-number |
9227297 |
|
Call sign |
D5GE3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2002 - 2004 Liberia, Monrovia - Call sign: ELZJ4 2004 - 2014 Germany, Hamburg - Call sign: DPRB |
|
GT |
45.803 t |
|
DWT |
Summer: 53.328 t |
|
NT |
25.077 t |
|
Number of 20ft containers |
4.112 |
|
Number of 40ft containers |
718 |
|
Reefer points |
1.300 |
|
Length |
281,03 m overall 268,00 m between perpendiculars |
|
Breadth |
32,20 m extreme |
|
Draught |
12,50 m |
|
Forecastle |
134,05 m |
|
Bridge |
118,65 m |
|
Poop |
15,40 m |
|
Depth |
19,85 m |
|
Speed |
Service: 25,1 knots |
|
Built |
2002 |
|
Keel laid |
31/08/2001 |
|
Launch date |
11/11/2001 |
|
Date of completion |
23/01/2002 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje Shipyard 530, Jangpyeong-ri, Sinhyeon-eup Geoje , Gyeongsangnam-do 656-710 Republic of Korea |
|
Yard number |
1357 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
9 |
|
Continuous decks |
2 |
|
Main engine |
1x Sulzer 9RTA96C-B - 2 stroke single acting 9 cylinder 960 x 2.550 mm combustion engine 51.434 kW / 69.930 hp at 102,0 rpm Year of Manufacture: 2002 Manufacturer: HSD Engine Co., Ltd. 69 Sinchon-dong Changwon , Kyungnam 641-370 Republic of Korea |
|
Propellers |
1x Fixed pitch propeller - aft |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 40,2 m² 1x Steam boiler,exhaust gas heated - 9,0 bar Heating surface: 672,0 m² Year of Manufacture: 2001 Manufacturer: Aalborg Industries A/S Division Heaters Gasvaerksvej 24 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
1x Plant 6.600/440 V - 21.198 kVA 1x Plant 440 V - 250 kVA 1x Plant 24 V - 200 Ah |
|
Generators |
4x MAN 7L32/40 H main diesel generatorsets each 4.371 kVA 1x MAN 6L32/40 generators - 3.714 kVA |
|
Emergency generator |
1x L10TBA diesel generatorset 250 kVA |
|
Compressed air receivers |
2x Receivers each 12.900 litres - 33,0 bar 1x Receiver 300 litres - 33,0 bar 1x Receiver 150 litres - 7,7 bar |
|
Bow thruster |
1x Transverse thruster NAKASHIMA - 1.600 kW, forward |
|
Tank capacities |
Fuel oil: 8.519 m³ |
|
Anchor equipment |
3x Anchors weight each 12.300 kg Chain length: 687,50 m Diameter: 87 mm |
|
Cargo gear |
Gearless |
|
Crew size |
30 |
|
Crew |
26 |
|
ISM & commercial manager |
MSC Shipmanagement Limited MSC House, 8, Spyrou Kyprianou Avenue Limassol Cyprus |
|
Previous managers |
2002 - 2014 Reederei Claus-Peter Offen (GmbH & Co.) KG |
|
Operator |
MSC - Mediterranean Shipping Company |
|
Registered owner |
SFL Rafaela Inc. Care of MSC Mediterranean Shipping Co., SA chemin Rieu, 12-14 1208 Geneva Switzerland |
|
Previous owners |
2002 - 2014 Kommanditgesellschaft MS "SANTA RAFAELA" Offen Reederei GmbH & Co. |
|
Latest data adjustment |
29 May 2023 |
