Westerschelde 23 July 2017 |
 |
 |
 |
 |
 |
||||
| Westerschelde 09/09/16 | Westerschelde 23/12/16 | Westerschelde 23/12/16 | Westerschelde 23/12/16 | Westerschelde 13/01/17 | ||||
|
Name |
HELLE RITSCHER |
|
Previous names |
2006 build as Helle Ritscher 03/2006 - 10/2009 Dal East London |
|
Type |
Cellular containership Sietas Typ 170 |
|
IMO-number |
9333371 |
|
Call sign |
A8IS6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
17.360 t |
|
DWT |
Summer: 22.254 t |
|
NT |
9.038 t |
|
Number of 20ft containers |
1.856 |
|
Container capacity 14t |
1.275 |
|
Reefer capacity |
385 |
|
Length |
178,57 m overall 167,50 m between perpendiculars 168,65 m registered |
|
Breadth |
26,00 m overall |
|
Draught |
10,85 m |
|
Forecastle |
42,53 m |
|
Poop |
15,52 m |
|
Freeboard |
3.720 mm |
|
Depth |
14,58 m moulded |
|
Speed |
21,8 knots |
|
Built |
2006 |
|
Keel laid |
25/11/2004 |
|
Launch date |
13/12/2005 |
|
Date of completion |
19/05/2006 |
|
Builder casco |
Daewoo Mangalia Heavy Industries Mangalia Romania Yard number: 4057 |
|
Builder completion |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany Yard number: 1271 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Single hull Double bottom |
|
Watertight bulkheads |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6L70ME-C - 2 stroke single acting 6 cylinder 700 x 2.360 mm combustion engine 16.980 kW / 23.083 hp Year of manufacture: 2005 Manufacturer: IZAR Construcciones Navales, S.A. Astillero Sestao 48910 Bilbao Spain |
|
Propellers |
1x Solid propeller (keyless) - aft |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 20,0 m² 1x Exhaust gas heated - 9,0 bar Heating surface: 495,0 m² Year of manufacturer: 2006 Manufacturer: Aalborg Industries A/S Gasvaerksvej 24 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
1x 450/230 V - 5.140 kVA 1x 450 V - 220 kVA 1x 24 V - 310 Ah |
|
Generators |
4x Yanmar 6N21AL-EV main diesel generatorsets each 1.285 kVA / 1.028 kW |
|
Emergency generator |
1x MAN D2866TE diesel generatorset 220 kVA / 176 kW |
|
Batteries |
2x Batteries for Start emergency engine each 155 Ah |
|
Compressed air receivers |
2x Receivers each 7.000 litres - 30,0 bar 1x Receiver 150 litres - 30,0 bar |
|
Thrusters |
1x Transverse thruster - 900 kW, forward 1x Transverse thruster - 700 kW, aft |
|
Tank capacities |
Ballast: 6.613 m³ |
|
Anchor equipment |
3x Anchors weight each 7.800 kg Chain length: 632,50 m Diameter: 68 mm |
|
Cargo gear |
3x Cranes - SWL 45 t each |
|
Manager |
Transeste Schiffahrt GmbH Jork Germany |
|
Registered owner |
Reederei MS "Helle Ritscher" GmbH & Co. KG |
|
Latest data adjustment |
31 March 2024 |
