Derby D IMO 9278117 02

Westerschelde 26 April 2016


Derby D 01   Derby D IMO 9278117 03   Derby D IMO 9278117 06   Derby D IMO 9278117 04   Derby D IMO 9278117 05
Westerschelde 04/01/17   Westerschelde 25/04/16   Westerschelde 22/05/15   Westerschelde 22/05/15   Westerschelde 22/05/15


Name

DERBY D

Previous names

2004 - 12/2005 P&O Nedlloyd Caracas

12/2005 - 04/2009 Maersk Derby

04/2009 - 04/2009 Derby

04/2009 - 05/2011 Bunga Raya Tiga

Type

Cellular containership - Panamax

IMO-number

9278117

Call sign

A8MY7

Flag

Liberia

Port of registry

Monrovia

GT

40.030 t

DWT

Summer: 50.814 t

NT

24.450 t

Number of 20ft containers

4.253

Container capacity 14t

2.875

Reefer capacity

400

Length

260,05 m overall

244,80 m between perpendiculars

Breadth

32,29 m extreme

Draught

Summer: 12,62 m

Depth

19,30 m moulded

Speed

Max.: 24,5 knots

Built

2004

Keel laid

24/11/2003

Launch date

14/02/2004

Date of completion

03/04/2004

Builder

Samsung Heavy Industries Co. Ltd., Koje Shipyard

South Korea

Yard number

1456

Hull material

Steel

Bulkheads

Transverse: 9

Longitudinal: 2

Main engine

1x HSD/MAN-B&W 8K90MC-C - 8 cylinder combustion engine Mcr 37.260 kW / 49.690 bhp

Propellers

1x Mono-block propeller

Builder: Nakashima Propeller Co., Ltd.

Boilers

1x Auxiliary boiler, oil/gas fired

Builder: KangRim Industries. Co., Ltd.

Generators

4x Daihatsu 6DK-28 diesel generatorset each 1.810 kW

Builder: Daihatsu Diesel Mfg. Co., Ltd.

Emergency generator

1x Cummins diesel generatorset

Bow thruster

1.600 kW

Number of holds

7

Number of hatches

16

Tank capacity

Ballast: 11.642 m³

Anchor equipment

Length: 687,50 m

Diameter: 87 mm

Cargo gear

Gearless

ISM & commercial manager

Danaos Shipping Co. Ltd.

14, Akti Kondyli

185 45 Piraeus

Greece

Registered owner

Containers Lines Inc.

Care of Danaos Shipping Co. Ltd.

14, Akti Kondyli

185 45 Piraeus

Greece

Previous owner

Fastcarrier No 2 Corporation

Latest data adjustment

10 April 2023
