Westerschelde 23 April 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 27/02/16 | Zeebrugge 13/08/09 | Zeebrugge 05/12/08 | Zeebrugge 05/12/08 | Westerschelde 12/07/20 | Westerschelde 26/04/20 | |||||
 |
||||||||||
| Westerschelde 01/01/16 | ||||||||||
|
Name |
CMA CGM OTELLO |
|
Type |
Cellular Containership |
|
IMO-number |
9299628 |
|
Call sign |
FMEJ |
|
Flag |
France |
|
Port of registry |
Marseille |
|
Previous flag |
2005 - 2007 Bahamas, Nassau 2007 - 2010 French Southern & Antarctic Territories, Port aux Français |
|
GT |
91.410 t |
|
DWT |
Summer: 101.811 t |
|
NT |
48.921 t |
|
Number of 20ft containers |
8.488 |
|
Container capacity at 14t |
6.143 |
|
Reefer capacity |
700 |
|
Length |
334,07 m overall 314,71 m between perpendiculars |
|
Breadth |
42,80 m over all |
|
Draught |
Summer: 14,50 m |
|
Keel to mast end |
61,60 m |
|
Freeboard |
5.749 mm |
|
Depth |
24,60 m |
|
Speed |
23,0 knots |
|
Built |
2005 |
|
Date of completion |
25/11/2005 |
|
Builder |
Hyundai Heavy Industries Co. Ltd. Ulsan South Korea |
|
Yard number |
H1646 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Watertight compartments |
10 |
|
Main engine |
1x MAN-B&W 12K98MC Mk VI - 2 stroke 12 cylinder 980 x 2.660 mm combustion engine 68.640 kW / 93.261 hp at 94,0 rpm Built: 2005 Builder: Hyundai Heavy Industries, Ulsan - South Korea |
|
Number of screws |
1x Fixed pitch propeller - aft at 94,0 rpm |
|
Boilers |
1x CHO Aalborg 40,14 m² - 10,0 bar 1x CHR Aalborg 736,00 m² - 10,0 bar |
|
Electrical installation |
Power voltage: 6.600 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
3x MAN-B&W 7L27/38 main diesel generatorsets each 2.933 kVA - 2.346 kW - 3.139 hp 2x MAN-B&W 9L27/38 main diesel generatorsets each 3.733 kVA - 2.986 kW - 4.031 hp |
|
Emergency generator |
1x Diesel generatorset 625 kVA - 500 kW - 815 hp |
|
Bow thruster |
1x 2.500 kW |
|
Number of holds |
9 |
|
Tank capacities |
Fuel: 14.137,60 m³ |
|
Lifting equipment |
2x Cranes - SWL 12,5 t each |
|
Cargo gear |
Gearless |
|
Crew |
34 |
|
Managing owners |
CMA CGM Marseille France |
|
Operator |
CMA CGM |
|
Registered owner |
CMA CGM SA The French Line 4, quai d'Arenc 13002 Marseille France |
|
Previous owner |
Gie Opera 5 Bail Kerguelen Islands |
|
Latest data adjustment |
20 May 2023 |
