Westerschelde 13 January 2017 |
 |
 |
 |
||
| Westerschelde 13/01/17 | Westerschelde 13/01/17 | Westerschelde 11/04/16 | ||
|
Name |
E.R. LONG BEACH |
|
Previous names |
2004 -2004 E.R. Long Beach 09/2004 - 06/2013 COSCO Shenzhen 06/2013 - 2016 MSC Shenzhen |
|
Type |
Cellular containership |
|
IMO-number |
9285653 |
|
Call sign |
LXSZ |
|
Flag |
G.D. Luxembourg |
|
Port of registry |
Luxembourg City |
|
Previous flags |
Liberia, Monrovia |
|
GT |
83.133 t |
|
DWT |
Summer: 99.066 t |
|
NT |
51.532 t |
|
Light ship |
29.190 t |
|
Number of 20ft containers |
7.455 |
|
Container capacity 14t |
5.650 |
|
Reefer capacity |
500 |
|
Length |
300,05 m overall 286,00 m between perpendiculars |
|
Breadth |
42,86 m extreme |
|
Draught |
15,00 m |
|
Depth |
24,60 m |
|
Speed |
Service: 24,0 knots Max.: 25,2 knots |
|
Built |
2004 |
|
Keel laid |
06/04/2004 |
|
Launch date |
26/06/2004 |
|
Date of completion |
17/09/2004 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
1543 |
|
Hull material |
Steel |
|
Main engine |
1x Wärtsilä-Sulzer 12RTA96C-B - 2 stroke single acting 12 cylinder 960 x 2.500 mm combustion engine 68.640 kW / 94.655 hp at 102,0 rpm Builder: Hyundai Heavy Industries Co Ltd. - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 102,0 rpm |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated type AQ-2, vertical smoke tube 1x Auxiliary boiler, oil/gas fired type Mission OS |
|
Generators |
2x MAN B&W 7L27/38 main diesel generatorsets each 1.995 kW 2x MAN B&W 9L27/38 main diesel generatorsets each 2.565 kW |
|
Emergency generator |
1x Cummins KTA-19-D(M) diesel generatorset |
|
Bow thruster |
1x 2.500 kW |
|
Tank capacities |
Ballast: 21.916,2 m³ |
|
Anchor equipment |
Length: 742,50 m Diameter: 102 mm |
|
Cargo gear |
Gearless |
|
Manager |
E.R. Schiffahrt GmbH & Cie. KG Hohe Bleichen 12 20354 Hamburg Germany |
|
Registered owner |
MS "E.R. LONG BEACH" Schiffahrtsges. mbH & Co. KG |
|
Renamed |
07/2017 E.R. Montecito G.D. Luxembourg, Luxembourg City – Call sign: LXSZ 11/2019 GSL Grania Liberia, Monrovia – Call sign: D5QI5 Owner: Global Ship Lease 32 LLC, 145 61 Athens - Greece ISM manager: Technomar Shipping Inc.,145 61 Athens - Greece Commercial manager: Conchart Commercial Inc. |
|
Latest data adjustment |
23 April 2024 |
