Westerschelde 15 January 2017 |
 |
 |
|
| Westerschelde 19/06/16 | Westerschelde 12/03/17 | |
|
Name |
MAERSK SHAMS |
|
Previous names |
01/12/2015 - 06/12/2015 Matisse |
|
Type |
Cellular containership - Post-Panamax |
|
IMO-number |
9726669 |
|
Call sign |
9V5255 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
01/12/2015 - 03/11/2016 Marshall Islands, Majuro - Call sign: V7PB8 |
|
GT |
94.730 t registered |
|
DWT |
117.175,5 t |
|
NT |
52.150 t registered Panama: 94.349 t |
|
Number of 20ft containers |
9.971 |
|
Container capacity 14t |
7.280 |
|
Reefer capacity |
1.400 |
|
Length |
299,92 m overall 287,00 m between perpendiculars |
|
Breadth |
48,20 m moulded |
|
Draught |
15,02 m |
|
Freeboard |
5.256 mm |
|
Depth |
24,80 m moulded |
|
Speed |
24,0 knots |
|
Keel laid |
01/06/2015 |
|
Launch date |
02/10/2015 |
|
Date of completion |
01/12/2015 |
|
Builder |
Hyundai Heavy Ind. Co., Ltd. Ulsan South Korea |
|
Yard number |
2688 |
|
Hull material |
High strength steel |
|
Watertight bulkheads |
9 |
|
Main engine |
1x MAN-B&W/Hyundai 9S90ME-C9.2 - 2 stroke single acting 9 cylinder 900 x 3.260 mm combustion engine Mcr 52.290 kW / 71.063 hp at 84,0 rpm Manufacturer: HHI Engine & Machinery Div. |
|
Propellers |
1x Fixed pitch propeller - aft at 84,0 rpm Manufacturer: HHI Engine & Machinery Div. |
|
Boilers |
1x Exhaust gas economizer - 9,0 bar 1x Fired boiler - 8,83 bar Manufacturer: Kangrim Heavy Industries Co., Ltd. |
|
Generators |
2x Main diesel generatorsets each 4.400 kW 2x Main diesel generatorsets each 3.840 kW Manufacturer: HHI Electro Electric System |
|
Number of holds |
7 |
|
Number of tanks |
Ballast: 19 Fuel oil: 10 Lubricating oil: 7 Diesel oil: 6 Waste water: 5 Fresh water: 3 Chain: 2 Sludge: 1 |
|
Tank capacities 100% |
Diesel oil: 844,4 m³ Freshwater: 606,6 m³ Fuel oil: 7.500,3 m³ Lube oil: 386 m³ Tank ballast: 2.8461,1 m³ |
|
Lifting equipment |
2x Engine room crane aft & forward - SWL 12,5 t each 1x Monorail crane - SWL 12,5 t 2x Provision crane port & starboard - SWL 4,0t each Manufacture: Oriental Prec & Eng'g Co. |
|
Manager |
Maersk A/S Copenhagen Denmark |
|
Previuos manager |
Neom Maritime (Singapore) Pte Ltd. - republic Singapore |
|
Operator |
Maersk Line |
|
Registered owner |
Chromis Pte. Ltd. |
|
Previous owner |
Yuki Shipping Pte Ltd. |
|
Latest data adjustment |
20 October 2024 |
