Westerschelde 14 May 2020 |
 |
| Westerschelde 28/01/17 |
|
Name |
MSC SINDY |
|
Type |
Cellular containership |
|
IMO-number |
9336048 |
|
Call sign |
3EKJ3 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
107.849 t |
|
DWT |
Summer: 117.077,4 t |
|
NT |
61.479 t |
|
Number of 20ft containers |
9.580 |
|
Container capacity 14t |
7.450 |
|
Reefer capacity |
700 |
|
Length |
336,63 m overall 321,00 m between perpendiculars |
|
Breadth |
45,63 m extreme |
|
Draught |
14,50 m |
|
Keel to mast end |
63,41 m |
|
Forecastle |
161,00 m |
|
Bridge |
150,60 m |
|
Poop |
10,40 m |
|
Freeboard |
4.738 mm |
|
Depth |
27,20 m |
|
Speed |
Max.: 26,1 knots |
|
Built |
2007 |
|
Keel laid |
09/01/2007 |
|
Launch date |
20/03/2007 |
|
Date of completion |
14/05/2007 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje Shipyard |
|
Yard number |
1611 |
|
Hull material |
Steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
11 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 12K98MC-C - 2 stroke 12 cylinder 980 x 2.400 mm combustion engine 68.520 kW / 93.158 hp at 104 rpm Year of manufacture: 2006 Manufacturer: Doosan Engine Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller - aft at 104 rpm |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated - 10,0 bar Built: 2006 Heating surface: 1.182,0 m² 1x Auxiliary boiler, oil/gas fired - 10,0 bar Built: 2007 Heating surface: 55,0 m² Manufacturer: Aalborg Industries (Shanghai) Ltd. |
|
Electric installations |
1x Plant 6.600 V - 3.437,5 kVA 1x Plant 6.600 V - 3.437,5 kVA 1x Plant 6.600 V - 3.437,5 kVA 1x Plant 6.600 V - 3.437,5 kVA 1x Plant 450 V - 625 kVA 1x Plant 24 V - 92 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 215 Ah 1x Plant 24 V - 300 Ah 1x Plant 110 V - 360 Ah |
|
Generators |
4x MAN B&W 6L32/40 main diesel generatorsets each 2.750 kW / 3.437,5 kVA |
|
Emergency generator |
1x Cummins VTA28-DMGE diesel generatorset 625 kVA |
|
Batteries |
2x Batteries for Automation each 360 Ah 1x Battery for UPS Navigation 300 Ah 1x Battery for Start emergency engine 215 Ah 1x Battery for UPS Radio 200 Ah 2x Batteries for Automation each 92 Ah |
|
Compressed air receivers |
2x Receivers each 14.500 litres - 30,0 bar 1x Receiver 300 litres - 30,0 bar 1x Receiver 250 litres - 8,3 bar |
|
Bow thruster |
1x Transverse thruster 3000 kW, forward |
|
Tank capacities |
Ballast: 25.307,7 m³ |
|
Anchor equipment |
3x Anchors weight each 20.000 kg Length: 759,00 m Diameter: 111 mm |
|
Cargo gear |
Gearless |
|
Crew size |
34 |
|
Commerical manager |
MSC Mediterranean Shipping Co. chemin Rieu, 12-14 1208 Geneva Switzerland |
|
ISM manager |
Mediterranean Shipping Company S.r.l. Via Francesco Ciampa 29 80063 Piano di Sorrento NA Italy |
|
Previous owners |
Compania Naviera Silvana S.A. Care of MSC Mediterranean Shipping Co., SA chemin Rieu, 12-14 1208 Geneva Switzerland |
|
Latest data adjustment |
28 January 2022 |
