Westerschelde 22 May 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 22/05/16 | Westerschelde 28/02/18 | Westerschelde 29/09/18 | Westerschelde 02/08/17 | Westerschelde 02/08/17 | Westerschelde 09/04/20 | |||||
|
Name |
YM WITNESS |
|
Type |
Cellular containership |
|
IMO-number |
9704609 |
|
Call sign |
VROL6 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
145.324 |
|
DWT |
145.091 t |
|
NT |
66.967 |
|
Number of 20ft containers |
On deck: 7.914 In hold: 6.166 Total: 14.080 |
|
Container capacity 14t |
10.150 |
|
Reefer capacity |
1.000 |
|
Length |
368,08 m overall 352,00 m between perpendiculars |
|
Breadth |
51,06 m extreme |
|
Draught |
16,02 m |
|
Depth |
25,63 m |
|
Speed |
Service: 23,2 knots Max: 24,7 knots |
|
Built |
2015 |
|
Keel laid |
02/03/2015 |
|
Launch date |
08/05/2015 |
|
Date of completion |
29/06/2015 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
2643 |
|
Hull material |
Higher tensile steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 11S90ME-C9.2 - 2 stroke single acting 11 cylinder 900 x 3.260 mm combustion engine 53.723 kW / 71.682 hp at 79,0 rpm Builder: Hyundai Heavy Industries Co Ltd - South Korea |
|
Propellers |
1x Mono-block fixed pitch propeller - aft at 79,0 rpm |
|
Boilers |
1x Auxiliary boiler, exhaust gas eEconomiser 1x Auxiliary boiler, oil/gas fired Builder: KangRim Heavy Industries Co., Ltd. |
|
Generators |
2x Daihatsu 6DC32 diesel engines each 2.950 kW connected with generators each 2.800 kW / 6.600 Volt 60 Hz 2x Daihatsu 8DC32 diesel engines each 3.900 kW connected with generators each 3.700 kW / 6.600 Volt 60 Hz Builder: Daihatsu Diesel Mfg. Co., Ltd. Moriyama Division |
|
Bow thruster |
1x Controllable pitch thruster 1.500 kW / 2.039 bhp, forward 1x Fixed pitch thruster 1.500 kW / 2.039 bhp, forward |
|
Number of holds |
10 |
|
Tank capacities |
Ballast: 38.330,6 m³ |
|
Anchor equipment |
Length: 770,0 mm Diameter: 127 mm |
|
Cargo gear |
Gearless |
|
Crew size |
27 |
|
Manager |
Seaspan Shipmanagement Ltd. Suite 2600 200, Granville Street Vancouver BC V6C 1S4 Canada |
|
Operator |
Yang Ming Marine Transport Corporation |
|
Registered owner |
Seaspan Holdco LVIII Ltd. |
|
Latest data adjustment |
16 February 2024 |
