Name |
LIBERTAS-H |
|
Previous names |
2007 - 11/2008 Libertas-H 11/2008 - 09/2009 CMA CGM Safi |
|
Type |
Containership |
|
IMO-number |
9388388 |
|
Call sign |
CQJB |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flags |
2007 - 2011 Antigua & Barbuda, St. John’s 2011 - 2013 Cyprus, Limassol |
|
GT |
7.532 t |
|
DWT |
Summer: 8.716,6 t |
|
NT |
3.553 t |
|
Number of 20ft containers |
724 |
|
Container capacity 14t |
444 |
|
Reefer capacity |
156 |
|
Length |
126,85 m overall 119,54 m between perpendiculars |
|
Breadth |
20,47 m extreme |
|
Draught |
Max: 7,75 m |
|
Depth |
10,35 m to main deck |
|
Speed |
Max: 18,5 knots |
|
Built |
2007 |
|
Keel laid |
22/11/2004 |
|
Launch date |
13/08/2007 |
|
Date of completion |
28/09/2007 |
|
Builder |
Cassens Schiffswerft und Maschinenfabrik GmbH Emden Germany |
|
Yard number |
250 |
|
Hull material |
Steel |
|
Main engine |
1x MaK 8M43C - 4 stroke 8 cylinder 430 x 610 mm combustion engine 7.200 kW / 9.789 hp at 514 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, oil fired 1x Thermal oil heater, exhaust heated (Economiser) |
|
Shaft generator |
1x 1.032 kW / 1.290 kVA |
|
Generators |
2x MaK 6M20 main diesel generatorsets each 960 kW / 1.200 kVA |
|
Emergency generator |
1x Caterpillar 9C DITA diesel generatorset 262 kVA |
|
Bow thruster |
1x 500 kW |
|
Number of holds |
3 |
|
Cargo hold capacity |
Grain: 11.835 m³ |
|
Number of hatches |
3 |
|
Tank capacities |
Ballast: 4.542,1 m³ |
|
Anchor equipment |
Length: 550 m Diameter: 52 mm |
|
Cargo gear |
Gearless |
|
ISM & commercial manager |
Reederei Hinsch Gmbh & Co KG Rudolf-Diesel-Straße 2 21614 Buxtehude Germany |
|
Registered owner |
UMS Schifffahrts Gmbh & Co KG Care of Reederei Hinsch Rudolf-Diesel-Strasse 22 21614 Buxtehude Germany |
|
Latest data adjustment |
19 January 2023 |
