Westerschelde 05 November 2018 |
 |
 |
 |
 |
 |
 |
 |
||||||
| Zeebrugge 22/09/07 | Westerschelde 07/05/15 | Westerschelde 07/05/15 | Westerschelde 24/03/19 | Westerschelde 24/07/17 | WS 24/07/17 | Westerschelde 23/07/15 | ||||||
|
Name |
ELLY MAERSK (ELLY MÆRSK) |
|
Type |
Cellular Containership - Carriage of dangerous goods |
|
IMO-number |
9321536 |
|
Call sign |
OXHY2 |
|
Flag |
Kingdom of Denmark |
|
Port of registry |
Svendborg |
|
GT |
171.542 t Suez: 171.347,16 t |
|
DWT |
Summer: 158.200 t |
|
NT |
62.537 t Suez: 152.109,93 t |
|
Displacement |
218.788 t |
|
Number of 20ft containers |
13.460 |
|
Reefer capacity |
1.000 |
|
Length |
398,90 m overall 376,00 m between perpendiculars |
|
Breadth |
56,40 m moulded |
|
Draught |
Summer: 16,00 m |
|
Freeboard |
6.670 mm |
|
Depth |
30,20 m moulded |
|
Speed |
24,5 knots |
|
Built |
2007 |
|
Keel laid |
07/02/2007 |
|
Launch date |
28/06/2007 |
|
Delivery date |
05/09/2007 |
|
Builder |
Odense Steel Shipyard AS (Staalskibsværft A/S) Lindoeallen 150 Munkebo DK-5330 Denmark |
|
Yard number |
L208 |
|
Hull material |
High strength steel |
|
Hull type |
Single hull |
|
Bulkhead |
Non tight: 11 Water tight: 11 Oil tight: 13 |
|
Main engine |
1x Doosan/Sulzer 14RT-Flex96C - 14 cylinder 960 x 2.500 mm combustion engine Mcr 80.080 kW at 102,0 rpm Manufacturer name: Doosan Engine Co. Ltd. |
|
Propeller |
1x Fixed pitch propeller Six blade solid bronze propeller - Diameter: 9.500 mm Manufacturer name: Mecklenburger Metallguss GmbH |
|
Turbo generator |
1x Combo power / steam turbine generator - 10.625 kVA / 8.500 kW Manufacturer name: Sem Drasov |
|
Shaft motor |
2x 9.000 kW Manufacturer name: Siemens AG |
|
Generators |
5x MaK 6M43 Main diesel generatorsets each 5.925 kVA / 4.148 kW Manufacturer name: Sem Drasov |
|
Boilers |
1x Vertical water tube oil fired auxiliary boiler AQ-10/12W - 14,0 bar Total Heating Surface: 55.000 mm² 1x HP Exhaust gas boiler AV-6N - 14,0 bar 1x LP Exhaust gas boiler AV-6N - 12,0 bar Builder: Aalborg Industries Aalborg - Denmark |
|
Cargo capacity |
Grain: 355.190,74 m³ Hold: 355.164,10 m³ |
|
Number of tanks |
Ballast: 31 Fuel oil: 22 Lubricating oil: 8 Sea water: 7 Fresh water: 7 Waste water: 6 Sludge: 6 Diesel oil: 6 Chain: 2 Hydraulic oil: 1 |
|
Tank capacities |
Ballast: 62.281,7 m³ Diesel oil: 405 m³ Fresh water: 752,60 t Fuel oil: 16.920,30 m³ Lube oil: 652,1 m³ Hydraulic oil: 5,70 m³ |
|
Lifting equipment |
1x Monorail stores crane - SWL 20,0 t 1x Stores/bunker/suez boat pedestal crane port - SWL 5,0 t 1x Stores/bunker/suez boat pedestal crane starboard - SWL 5,0 t Manufacturer: Dreggen A/S 1x Overhead engine room crane aft - SWL 12,5 t 1x Overhead engine room crane forward - SWL 12,5 t Manufacturer: Danish Crane Building A/S |
|
Cargo gear |
Gearless |
|
Crew |
28 |
|
Manager |
A.P. Möller Maersk A/S Esplanaden 50 CopenhagenK, DK-1098 Denmark |
|
Registered owner |
Maersk A/S Esplanaden 50 1263 København K Denmark |
|
Latest data adjustment |
13 July 2023 |
