Westerschelde 25 April 2017 |
 |
 |
 |
||
| Antwerpen 02/01/18 | Antwerpen 02/01/18 | Antwerpen 07/05/18 | ||
|
Name |
NORDISABELLA |
|
Type |
Cellular containership |
|
IMO-number |
9697014 |
|
Call sign |
5BLD4 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
28.316 t Suez: 29.942,65 t |
|
DWT |
35.586,5 t |
|
NT |
12.334 t Panama: 23.550 t Suez: 25.876,43 t |
|
Number of 20ft containers |
2.506 |
|
Container capacity 14t |
1.984 |
|
Reefer capacity |
In hold: 289 On deck: 241 Total: 530 |
|
Length |
194,87 m overall 184,93 m between perpendiculars |
|
Breadth |
32,25 m extreme 32,19 m moulded |
|
Draught |
11,50 m |
|
Freeboard |
5.530 mm |
|
Depth |
16,50 m |
|
Speed |
Max.: 18,0 knots |
|
Built |
2016 |
|
Keel laid |
08/06/2015 |
|
Launch date |
29/08/2015 |
|
Date of completion |
19/01/2016 |
|
Builder |
Guangzhou Wenchong Shipyard Co.,Ltd. No. 1 Wenchuan Road Hongshan Street Huangpu, Guangzhou, 510725 China |
|
Yard number |
GWS449 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 6G60ME-C 9.2 - 4 stroke 6 cylinder 600 x 2.790 mm combustion engine 12.832 kW at 97,0 rpm Manufacturer: Hudong Heavy Machinery Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, composite |
|
Generators |
2x MAN-B&W 5L27/38 main diesel generatorsets each 1.350 kW 2x MAN-B&W 7L27/38 main diesel generatorsets each 1.995 kW |
|
Emergency generator |
1x MAN D2866LXE20 diesel generatorset |
|
Tank capacities |
Ballast: 12.256,11 m³ Diesel oil: 219,08 m³ Fuel oil: 4.696,44 m³ Fresh water: 167,41 m³ Lub oil: 277,40 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Cargo gear |
3x Deck cranes - SWL 45,0 t each |
|
Manager |
Reederei Nord GmbH Astraturm Zirkusweg 2 20359 Hamburg Germany |
|
Registered owner |
Nord Isabella GmbH & Co. KG |
|
Renamed |
11/2019 Maersk Bermuda Republic of Singapore, Singapore City - Call sign: 9V6595 Registered owner: Xiang L42 HK International Ship Lease Co. Limited |
|
Latest data adjustment |
13 January 2021 |
