Name |
CMA CGM WHITE SHARK |
|
Type |
Cellular containership - Panamax |
|
IMO-number |
9317975 |
|
Call sign |
9HA5021 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
United Kingdom, London- Call sign: MPXV7 until 2019 |
|
GT |
54.309 t Suez: 55.817 t |
|
DWT |
Summer: 65.892,5 t |
|
NT |
34.011 t Suez: 48.768 t |
|
Number of 20ft containers |
In hold: 2.203 On deck: 2.892 Total: 5.095 |
|
Container capacity 14t |
3.306 |
|
Reefer points |
330 |
|
Length |
294,12 m overall 278,73 m between perpendiculars |
|
Breadth |
32,20 m |
|
Draught |
Summer: 13,52 m |
|
Freeboard |
3.867 mm |
|
Depth |
21,80 m |
|
Speed |
22,8 knots |
|
Built |
2007 |
|
Date of completion |
23/04/2007 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
1711 |
|
Hull material |
Steel |
|
Watertight compartments |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 10K98MC-C6-TI - 2 stroke single acting 10 cylinder 980 x 2.400 mm combustion engine 57.075 kW / 77.599 hp at 104,0 rpm Built: 2003 Manufacturer: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div. - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 104,0 rpm |
|
Boilers |
1x CHR Aalborg 392,00 m² - 7,0 bar 1x CHO Aalborg 40,14 m² - 7,0 bar |
|
Electric installations |
Power voltage: 450 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
3x Main diesel generatorsets each 3.000 kVA - 2.400 kW - 3.465 hp 450/220 Volt 60 Hz |
|
Emergency generator |
1x Diesel generatorset 250 kVA - 200 kW - 345 hp |
|
Bow thruster |
1x Tunnel thruster 1.800 kW / 2.447 bhp, forward |
|
Number of holds |
6 |
|
Tank capacities |
Fuel oil: 8.881,5 m³ |
|
Cargo gear |
Gearless |
|
Crew size |
19 |
|
Commerical manager |
CMA CGM SA The French Line 4, quai d'Arenc 13002 Marseille France |
|
ISM manager |
CMA CGM International Shipping 14-01, The Metropolis (Tower 1) 9, North Buona Vista Drive Singapore 138588 Republic of Singapore |
|
Registered owner |
SNC Fenice Bail 2 Care of CMA CGM SA (The French Line) 4, quai d'Arenc 13002 Marseille France |
|
Latest data adjustment |
12 May 2022 |
