Westerschelde 28 July 2018 |
 |
 |
|
| Westerschelde 20/04/19 | Westerschelde 08/02/20 |
|
Name |
GENOA |
|
Previous names |
09/2002 - 08/2015 Genoa Bridge |
|
Type |
Cellular containership |
|
IMO-number |
9267651 |
|
Call sign |
D5JI9 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
09/2002 - 08/2015 Republic of Panama, Panama City - Call sign: HOMF |
|
GT |
66.292 t registered Suez: 68.198,76 t |
|
DWT |
Summer: 67.197 t |
|
NT |
25.648 t registered Suez: 59.092,57 t |
|
Displacement |
91.250 t |
|
Number of 20ft containers |
5.576 |
|
Container capacity 14t |
4.170 |
|
Reefer capacity |
500 |
|
Length |
278,94 m overall 262,00 m between perpendiculars |
|
Breadth |
40,10 m |
|
Draught |
Summer: 14,02 m |
|
Freeboard |
5.420 mm |
|
Depth |
24,07 m moulded |
|
Speed |
25,0 knots |
|
Built |
2002 |
|
Keel laid |
22/03/2002 |
|
Launch date |
31/05/2002 |
|
Delivery date |
09/09/2002 |
|
Builder |
Koyo Dockyard Co. Ltd. (Imabari Shipbuilding Co., Ltd. group) Hiroshima Shipyard 2-1-1 Noji, Saizaki-Cho Mihara City, 729-2292 Japan |
|
Yard number |
2152 |
|
Hull material |
High strength steel |
|
Hull type |
Single hull |
|
Bulkheads |
Non tight: 5 Water tight: 20 Oil tight: 14 |
|
Main engine |
1x Mitsui/MAN-B&W 10K98MC-C - 10 cylinder 980 x 2.660 mm combustion engine 57.200 kW / 77.770 hp at 94,0 rpm Manufacturer name: Mitsui Engineering & Shipbuilding Co., Ltd. |
|
Propellers |
1 Manufacturer: Mitsubishi Heavy Industries, Ltd., Nagasaki - Japan |
|
Boilers |
1x Auxiliary Boiler - 8,16 bar Boiler heating surface: 47,0 m² 1x Exhaust gas boiler - 12,0 bar Builder: Osaka Boiler Manufacturing, Osaka - Japan |
|
Shaft generator |
1x 2.100 kW |
|
Generators |
4x Yanmar 6N330L-EV main diesel generatorsets each 2.200 kW Manufacturer name: Nishishiba Electric Co., Ltd. |
|
Bow thruster |
1x Kawasaki KT-219B3 - 2.000 kW / 2.682 hp |
|
Number of holds |
7 |
|
Number of hatches |
16 |
|
Number of tanks |
Ballast: 22 Fuel oil: 17 Sludge: 7 Lubricating: oil 7 Diesel oil: 3 Waste water: 2 Fresh water: 1 Potable water: 1 Chain: 1 Sea water: 1 |
|
Tank capacities |
Water ballast: 15.078,91 m³ Diesel oil: 380,82 m³ Freshwater: 391,90 m³ Fuel oil: 9.866,35 m³ Lube oil: 561,36 m³ |
|
Lifting equipment |
2x Bunkering Davit - SWL 0,9 t each 1x Monorail crane - SWL 9,5 t |
|
Cargo gear |
Gearless |
|
Manager |
Danaos Shipping Co Ltd. 14, Akti Kondyli Piraeus, Athens Greece |
|
Previous managers |
Kawasaki Kisen Kaisha, Tokyo - Japan |
|
Owner |
Aquila Carriers Corporation SA 53 Rd E Street, Urbanization Marbella mmg Tower 16th Floor Panama City Republic of Panama |
|
Registered owner |
Aquila Carriers Corporation SA Care of Danaos Shipping Co. Ltd., Piraeus - Greece |
|
Previous owners |
K-Line Ship Management Co., Ltd. - Japan |
|
Sister ships |
Ensenada - IMO - 9247546 Folegandros - IMO 9247560 Great - IMO 9267156 March - IMO 9298997 |
|
Renamed |
2021 Kota Lima Liberia, Monrovia - call sign: D5JI9 Manager: Danaos Shipping Co Ltd. - Greece |
|
Latest data adjustment |
20 June 2021 |
