Ital Contessa - IMO 9293806

Name

ITAL CONTESSA

Type

Cellular containership

IMO-number

9293806

Call sign

DDZF2

Flag

Germany

Port of registry

Hamburg

GT

90.449 t

DWT

101.007 t

NT

55.452 t

Number of 20ft containers

8.084

Reefer capacity

700

Length

333,99 m overall

319,00 m between perpendiculars

320,62 m registered

Breadth

42,80 m

Draught

Summer: 14,50 m

Forecastle

160,03 m

Bridge

149,63 m

Poop

10,40 m

Freeboard

4.875 mm

Depth

24,60 m

20,53 m tonnage

Speed

25,2 knots

Built

2006

Keel laid

17.10.2005

Launch date

24.12.2005

Date of completion

09.03.2006

Builder

Samsung Heavy Industries Co., Ltd. Geoje Shipyard
530, Jangpyeong-ri, Sinhyeon-eup
Geoje , Gyeongsangnam-do 656-710
Republic of Korea

Yard number

1527

Hull material

Shipbuilding steel (standard)

Hull type

Double bottom

Watertight bulkheads

11

Continuous decks

2

Main engine

1x Sulzer 12RTA96C-B - 2 stroke single acting 12 cylinder 960 x 2.500 mm diesel engine - 68.640 kW at 102 rpm

Year of manufacture: 2005

Manufacturer: Doosan Engine Co., Ltd.
69-3, Sinchon-dong
Changwon , Gyungnam 641-370
Republic of Korea

Propellers

1x Solid propeller (keyless) - aft at 102 rpm

Boilers

1x Steam boiler, oil fired - 10,0 bar
Heating surface: 40,14 m²

1x Steam boiler exhaust gas heated - 10,0 bar
Heating surface: 362,0 m²

Year of manufacture: 2005

Manufacturer: Aalborg Industries Ltd.
86 Guangzhou Road North Jiaozhou
266300 Qingdao , Shandong
People's Republic of China

Electric installations

1x Plant 6.600/450 V - 15.281,4 kVA

1x Plant 450 V - 625 kVA

1x Plant 24 V - 160 Ah

1x Plant 24 V - 200 Ah

1x Plant 24 V - 400 Ah

1x Plant 110 V - 125 Ah

Generators

2x MAN-B&W 9L27/38 main diesel generatorsets each 3.525 kVA / 2.820 kW

3x MAN-B&W 7L27/38 main diesel generatorsets each 2.743,8 kVA / 2.195 kW

Emergency generator

1x Diesel generatorset 625 kVA

Batteries

12x Batteries for UPS radio each 200 Ah

2x Batteries for automation each 160 Ah

Compressed air receivers

2x Receivers each 20.000 litres - 33,0 bar

1x Receiver 500 litres - 33,0 bar

1x Receiver 300 litres - 33,0 bar

1x Receiver 150 litres - 8,8 bar

Bow thruster

1x Transverse thruster - 2.500 kW, forward

Anchor equipment

3x Anchors weight each 18.800 kg

Chain length: 742,50 m

Cargo gear

Gearless

Crew

26

Crew size

34

Manager

NSB Niederelbe Schiffahrts GmbH & Co. KG
Harburger Str. 47-51
21614 Buxtehude
Federal Republic of Germany

Operator

Italia

Owner

Conti 16. Container GmbH & Co. KG MS "CONTI CONTESSA"
c/o NSB Niederelbe Schiffahrts GmbH & Co. KG
Harburger Str. 47-51
21614 Buxtehude
Federal Republic of Germany
