Westerschelde 18 July 2018 |
 |
| Westerschelde 23/05/18 |
|
Name |
E.R. HOBART |
|
Previous names |
2005 - 10/2007 TS Singapore 10/2007 - 07/2012 Ulrike F 07/2012 - 2016 Paola |
|
Type |
Gearless/Cellular fast container vessel |
|
IMO-number |
9306823 |
|
Call sign |
D5MH7 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
205 - 2018 Antigua & Barbuda, St. John’s - Call sign: V2BH9 |
|
GT |
9.931 t |
|
DWT |
Summer: 13.879,3 t |
|
NT |
5.032 t |
|
Number of 20ft containers |
In hold: 334 On deck: 784 Total: 1.118 |
|
Container capacity 14t |
713 |
|
Reefer capacity |
220 Whereof 56 plugs are fitted in hold no. 4A and 3B and 164 plugs are fitted on deck |
|
Length |
147,82 m overall 140,30 m between perpendiculars |
|
Breadth |
23,40 m extreme 23,25 m moulded |
|
Draught |
Max: 8,51 m |
|
Depth |
11,50 m |
|
Speed |
19,6 knots |
|
Built |
2005 |
|
Keel laid |
30/09/2004 |
|
Launch date |
10/04/2005 |
|
Date of completion |
27/09/2005 |
|
Builder |
China Chang Jiang National Shipping Group Corporation Jinling Shipyard China |
|
Yard number |
JLZ 030401 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 7L58/64 - 7 cylinder combustion engine 9.600 kW at 428 rpm |
|
Propellers |
1x Controllable pitch propeller- aft at 131 rpm Diameter: 5.400 mm |
|
Boilers |
1x Thermal oil heater, oil fired 1x Thermal oil heater, exhaust heated |
|
Shaft generator |
1x 1.750 kW |
|
Generators |
3x MAN 6L16/24 main diesel generatorsets each 610 kW |
|
Emergency/harbour gen. |
1x MAN D2842 LE 201 diesel generatorset 687,5 kVA |
|
Bow thruster |
700 kW |
|
Hold ventilation |
Hold 1: 6 air-changes/hour (ex-proof for dangerous goods) Hold 2-5: 2 air-changes/hour (holds 3 and 4 with additional capacity for reefer containers) |
|
Number of hatches |
No.1 : 14,0 x 10,4 m No.2 : 12,6 x 18,0 m No.3A : 12,6 x 18,0 m No.3B : 12,6 x 18,0 m No.4A : 12,6 x 18,0 m No.4B : 12,6 x 18,0 m No.5 : 12,6 x 18,0 m |
|
Hatch type |
Watertight pontoon hatch covers, non-sequential are arranged on main deck for No.1) hatch with one cover, No. 2) to 5) hatches with 2 covers each |
|
Tank capacities |
Water ballast: 5.044,26 m³ HFO: 1: 423,75 m³ MGO: 244,00 m³ Fresh water: 159,00 m³ Lubricating oil: 59,51 m³ |
|
Anchor equipment |
Length: 571,50 m Diameter: 60 mm |
|
Cargo gear |
Gearless |
|
Crew size |
20 men in single cabins and two spare cabins with double staged beds. All accommodation with air-conditioning |
|
Manager |
E.R. Schiffahrt GmbH & Cie. KG Hamburg Germany |
|
Renamed |
11/2018 Vega Vela Liberia, Monrovia - Call sign: D5MH7 Manager: Vega-Reederei GmbH & Co KG |
|
Latest data adjustment |
30 September 2020 |
